2026 Sun Tracker Party Barge 24 XP3
$76,370
Boat in Saint Charles, MO 63301 US
Built in 2026
Party Barge 24 XP3
1 Engine (MERCURY MARINE)
26.2 feet
--
Aluminum
The PARTY BARGE® 24 XP3 is the biggest pontoon in the SUN TRACKER® family. The 24' deck lets up to 12 passengers embark on aquatic adventures they'll never forget.
Each corner features a long pillow-top lounge with secret storage spaces under the seats and in the STOW MORE™ seat backs to give you all the space you need to pack snacks, equipment, supplies, and more. New to the 2026 model year are the backrest cubbies that give you extra easy-access storage space and cupholders. This new year also brings premium weave flooring and upholstery accents that match the color of your fencing.
The captain can control everything through the completely redesigned console's new SUN TRACKER FLARE™ touch-screen gauge display with an improved GPS system and upgraded four-speaker Bluetooth®-capable stereo.
With the most space and the longest list of exciting features, the 24 XP3 really brings the party wherever it goes!
Length:26' 2"
Deck Length: 24' 1"
Deck Width: 8' 6"
Max. Recommended HP: 250 HP
Fuel Capacity: 52 gal.
Pontoon Log Length: 24' 11"
Pontoon Log Diameter: 26"
Pontoon Log Material: 0.1 5052 marine alloy
Max. Person Capacity: 12 persons
Max. Person Weight: 1900 lbs.
Max. Person, Motor & Gear Weight: 2800 lbs.
Interior Depth: 27.25"
Average Dry Weight: 3360 lbs.
Average Package Weight: 5685 lbs.
Package Height: 8' 10"
Package Width: 8' 6"
Towing Length: 37' 9"
Storage Length: 37' 9"
Comfort, Convenience & Peace of Mind
10+LIFE™ Limited Lifetime Warranty: 10-year bow-to-stern warranty + limited lifetime structural & deck warranty
NMMA® certified
10' (3.05 m) Black SUN TRACKER® QuickLift™ Bimini top w/LED courtesy lights, storage pockets & protective boot
Integrated LED docking lights
Integrated LED navigation & anchor lights
4 folding mooring cleats & starboard side tie-off mooring eye
Port wheelchair-accessible gate
Rear boarding platform w/wide 4-step telescoping boarding ladder & grab rails
Aft receptacle base for optional ski tow pylon
Motor-stop safety lanyard
Fire extinguisher
Horn
Console
Driver console w/integrated storage, drink holders, built-in footrest & ergonomically-positioned controls
SUN TRACKER FLARE™ touchscreen gauge display w/integrated GPS & stereo control
12-button switch panel
Tilt hydraulic steering w/deluxe soft-touch steering wheel
4 Wet Sounds® 6.5" (16.51 cm) upholstery speakers, strategically located & shielded within the seat bases
Master power on/off switch
Recessed mobile phone cubbies
USB charging receptacle
Interior
Patented built-in STOW MORE™ seat-back storage system for all couches
Bow port couch w/STOW MORE™, underseat storage & armrest w/drink holder
Bow starboard console couch w/STOW MORE™ & underseat storage
2 fixed deluxe high-back swiveling bucket seats, reclining & w/self-leveling arms on bow port side
Bow port side drink holder
Integrated drink holders w/storage area
Removable table w/4 molded-in drink holders; color-coordinated, soft-touch mat; & tailored table location per dealer (dealer installed)
In-floor lighted storage compartment — 88" (2.24 m) long, 23" (58.42 cm) deep — w/bilge pump in center log
Reclining, high-back swiveling port & helm bucket seats w/self-leveling armrests
Aft port rear-facing double lounge w/STOW MORE™, underseat storage & pop-up changing room
Aft starboard couch w/STOW MORE™ & underseat, lockable storage
Bumper storage compartment
Interior courtesy lighting
Full-width aft swim deck
Woven 16-oz. (.45 kg) marine-grade flooring throughout
Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
Performance
Three 26" (66.04 cm) diameter high-buoyancy multichambered & internally-braced pontoon logs
XP3 performance strakes & wave-deflecting nose cone for maximum performance
Full-length, 1-piece longitudinal M-bracket deck supports
Full-width, heavy-duty extruded Z-bar deck supports that are thru-bolted to longitudinal M-brackets
Heavy-duty aluminum U-channel reinforcement behind bow deck trim
Reinforced bow & stern structures
All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
All-aluminum box-beam transom for strength & longevity
Factory-installed underpinning (under-deck shielding) for improved performance
Pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails
Sound- & vibration-deadening fence insulation for a quiet ride
Extruded & anodized aluminum deck edging w/polished aft corner covers
Precision fit & finish via plasma & laser-cut parts & robotically-welded construction
Rotomolded storage, furniture & console for superior strength & longevity
Nylon gate latches & heavy-duty hinges that open inward
Stainless or coated corrosion-resistant fasteners
Factory-matched aluminum propeller
Exterior
Color: Heritage Red, Pearl White, Sky Blue or Starlite Black fencing
Patent-pending TRACK FORMED® fence design w/high-sheen finish for long-lasting cosmetics
Full-height, elevated fence panels for deck drainage & ventilation
Electrical
500 GPH (1,893 LPH) Ultima automatic bilge pump
Battery disconnect switch
Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
Protective abrasion-resistant wire wrap
Water-resistant connectors
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice. All sales are final. No returns accepted.
Price History
| Date | Event | Price |
|---|---|---|
| 12/10/25 | Initial price | $76,370 |
2026 Sun Tracker Party Barge 24 XP3 Video Tours
Boattest.com Review
Overview
The SunTracker Party Barge 24XP3 is a pontoon boat clearly designed with family entertainment in mind. It comfortably accommodates up to 12 guests and offers a variety of seating and lounging options. This model emphasizes socializing and relaxation, making it a versatile platform for day outings on the water.
Exterior Design and Seating Layout
The boat's stern features a couch to starboard seating three to four people, with storage compartments beneath. Opposite this is a double-wide, aft-facing chase lounge that doubles as a sunning area. Moving forward into the cockpit, the flooring transitions from vinyl in the wet area to carpet in the dry area, though additional padding beneath the carpet would be beneficial. The cockpit includes an L-shaped sofa upholstered in UV-resistant marine-grade vinyl with multi-density foam padding, and an aluminum lock box for securing valuables. Two table mounts are provided—one centrally located in the cockpit and another in the bow area. The bow itself offers port and starboard couches with rotocast molded seats that resist rot and wood degradation. Portable drink holders attach via Velcro under the seats, and an under-seat cargo net adds storage capacity. A 9-foot color-matched BEMEDE top provides shade to keep the cockpit cool during sunny days.
Helm and Control Station
The helm station is designed with an elegant yet minimalist aesthetic, featuring a modest smoked windscreen above two gauges and a faux-wood panel. Switches flank both sides of the console, which includes a padded flat surface and a drink holder. The steering wheel is mounted on a tilt base, and engine controls are positioned nearly vertically for ease of use. Entertainment is managed via a Jensen stereo system with MP3 jack and Bluetooth streaming capabilities, supported by four directional speakers located fore and aft. The bucket helm seat is adjustable, swivels, and includes flip-up armrests, with comfortable multi-density foam upholstery. Underneath the helm console, there is space for a cooler and a dedicated fire extinguisher storage compartment. Navigation lights are mounted on the deck, though relocating them higher on the fences could reduce tripping hazards.
Power and Performance
The test boat was powered by an optional 200-horsepower Mercury Verado outboard, with the standard engine being 150 horsepower. The fuel fill is conveniently located ahead of the engine, with small platforms on either side to facilitate maintenance checks. The aft lounge lifts to reveal a properly secured battery compartment. The Party Barge 24XP3 measures 26 feet 2 inches in length overall with a beam of 8 feet 6 inches and an empty weight of 3,095 pounds. During testing, with an estimated weight of 4,067 pounds including fuel and two people, the boat reached a top speed of 40.5 miles per hour at 6,200 RPM, burning 19.75 gallons per hour and providing a range of approximately 65 miles. The optimal cruising speed was 15.4 miles per hour at 3,000 RPM, with a fuel burn of 3.2 gallons per hour, yielding a range of 152 miles and an endurance of nearly 10 hours with a 10% fuel reserve. Acceleration was brisk, with a time to plane of 3.4 seconds, 20 miles per hour reached in 4.4 seconds, and 30 miles per hour in 7.6 seconds. The triple-tube XP3 performance package allows the boat to plane from a fairly level attitude; adding trim raises the bow to improve cruising efficiency and handling by reducing spray. The boat handles gentle turns flatly, with slight leaning on harder turns, responding well to helm input and suitable for towing activities.
Swim Platform and Changing Room
At the stern, the Party Barge 24XP3 features a full-width swim platform equipped with a four-step reboarding ladder on the starboard side, facilitating easy water access. For privacy and convenience, a changing room is integrated into the design, deployable by pulling up on a handle and securing it in place. Inside, the space is ample enough to turn around comfortably, and a pop-up bench seat adds safety and seating within the enclosure.
Conclusion
Overall, the SunTracker Party Barge 24XP3 lives up to its name as an excellent entertainment platform. It offers ample seating, thoughtful amenities, and solid performance characteristics that make it well suited for family outings and social gatherings on the water. Its combination of comfort, functionality, and handling make it a compelling choice for those seeking a versatile pontoon boat.
Overview from around the web 2026 Sun Tracker Party Barge 24 XP3
Customers are raving about the 2026 Sun Tracker Party Barge 24 XP3, highlighting its spacious and comfortable design that's perfect for entertaining family and friends on the water
Many appreciate the smooth handling and reliable performance, making every outing enjoyable and stress-free. The quality craftsmanship and attention to detail, from the plush seating to the innovative features, receive high praise. Users also love the versatility of the boat, noting it’s great for everything from relaxing cruises to lively parties. Overall, the 24 XP3 stands out as a top choice for those seeking a fun, stylish, and dependable pontoon boat.
The Biggest Pros and Cons
The 2026 Sun Tracker Party Barge 24 XP3 offers a range of features that make it a popular choice for fun and relaxation on the water. Here are some of the pros and cons to consider:
Pros
Spacious Layout: The 24-foot length provides ample room for entertaining family and friends, with plenty of seating and open space.
Durability: Built with high-quality materials and a sturdy frame, ensuring long-lasting performance and safety.
Powerful Performance: Equipped with a reliable engine option that delivers smooth and efficient cruising.
Comfort Features: Includes plush seating, ample storage compartments, and optional amenities like a bimini top for shade.
Versatility: Suitable for a variety of water activities, from leisurely cruises to lively parties on the lake.
Easy Handling: Designed for stability and maneuverability, making it accessible for both new and experienced boaters.
Cons
Fuel Efficiency: Depending on the engine choice, fuel consumption can be higher compared to smaller models.
Limited High-Speed Performance: While great for cruising and socializing, it may not satisfy those seeking high-speed thrills.
Storage for Transport: Due to its size, transporting the pontoon may require a larger trailer and vehicle.
Customization Costs: Optional upgrades and accessories can add significantly to the overall price.
Made For
The 2026 Sun Tracker Party Barge 24 XP3 is perfect for families and groups who love spending time on the water in style and comfort. Whether you're hosting lively gatherings, enjoying leisurely cruises, or soaking up the sun with friends, this pontoon boat offers spacious seating, versatile features, and a smooth ride that caters to those seeking fun and relaxation on lakes and rivers. It's ideal for anyone looking to combine luxury, durability, and entertainment in one impressive package.
