2023 Nitro Z20 Boat in Smithfield, NC 27577 US
Built in 2023
Z20
1 Engine (Mercury)
20.2 feet
Gas
Fiberglass/Reinforced
Many professional tournament anglers choose the NITRO® Z20 because it competes with larger boats in regard to speed but is compact enough for probing docks and shallower water. The basis of the Z20 is the NITRO VORTEX TECHNOLOGY™ (NVT™) hull-a design that uses a series of parabolic curves for quicker holeshots, more lift while on plane and improved handling.
The Z20 is optimized for tournament angling with a Lowrance® fishfinder, two massive 8' bow rod lockers and an enormous center tackle storage compartment with the NITRO-exclusive TACKLE MANAGEMENT SYSTEM™. It comes fully rigged with a custom-matched, tandem-axle trailer with GALVASHIELD® Impact protection.
Length:20' 2"
Beam: 7' 10"
Bottom Width: 6' 3"
Max. Recommended HP: 250 HP
Fuel Capacity: 50 gal.
Max. Person Capacity: 4 persons
Max. Person Weight: 575 lbs.
Max. Person, Motor & Gear Weight: 1750 lbs.
Interior Depth: 18"
Transom Height: 22"
Deadrise: 16 degrees
Draft: 16"
Average Dry Weight: 2000 lbs.
Average Package Weight: 4050 lbs.
Package Height: 6' 1"
Package Width: 8' 6"
Towing Length: 27' 0"
Storage Length: 23' 8"
Comfort, Convenience & Peace of Mind
NMMA® certified
Flotation meets or exceeds NMMA® & U.S. Coast Guard requirements
EPA-compliant fuel system
Anti-fatigue, padded comfort bow deck
Non-skid bow & stern mats
5 drink holders
5 stainless steel pull-up cleats, including cleat at driver seat
4 grab handles (1 at each seat)
Fire extinguisher
Horn
Paddle
Livewell System
2 aft 19-gal. (71.92 L) insulated, rotomolded GUARDIAN™ livewells w/digital timers & rounded corners
500 GPH (1,892.71 LPH) aerator/fill pump
750 GPH (2,839.06 LPH) livewell recirculation/pump-out system
Dual remote drain controls
Trolling Motor
Minn Kota® Maxxum® 24V, 70-lb. (31.75 kg) thrust, 42" (1.07 m) shaft, foot-control trolling motor w/mount
Trolling motor pedal recess
Console
Modular, aerodynamic console design w/expanded leg clearance & large fishfinder surface
Removable acrylic, tinted windscreen
Lowrance® HOOK Reveal 5C flush-mounted fishfinder
NEW 5" (12.7 cm) digital touchscreen
Veethree® multifunction instrumentation w/speedometer/fuel gauge, tach/trim gauge, voltmeter gauge & water pressure gauge
Dash light dimmer
Tilt hydraulic steering
Below-console RAM® X-Grip® phone holder & 12V outlet
LED courtesy light
Ready to accept optional removable port console
Interior
42.5-sq.-ft. (4.0-sq.-m) anti-fatigue, padded bow deck for comfort & casting mobility
Bike seat w/pedestal
Folding fishing seat w/composite frame
Z-CORE™ seating system w/Force Flex suspension & contoured, rotomolded frame for driver & passenger seats
Low driver & passenger flat seat mounting
Bow tool/drink holder
Bow port & starboard rod hold-down straps
Molded-in drainage channels around bow storage compartments
Oversized, lockable bow port & starboard rod lockers w/lift assists for rods up to 8' (2.44 m)
Rod organizer in bow port rod locker
Oversized lockable bow center storage locker w/TACKLE MANAGEMENT SYSTEM™
Step to bow deck w/62-qt. (58.67 L) insulated cooler, removable trash receptacle & snap-in sandwich tray
Partner rod ramp w/rod handle organizer & hold-down strap
Footrest w/non-skid mat under console(s)
Step to aft deck w/lockable storage & removable tub
Designated net storage behind seating
Built-in tournament ruler & holder
2 lift-out, molded aft storage boxes that will each accept seven 3700 tackle trays
Molded utility rigging compartment for easy access to batteries & pumps & easy cleanup
Lift-out tool/rope storage tray in rigging compartment
Insulated aluminum lids w/welded corners
16-oz. (.45 kg) plush, marine-grade cut pile carpet on decks & floor
Lockable latches
Performance
NITRO VORTEX TECHNOLOGY™ (NVT™) hull for a smoother, drier ride
RAPID PLANING SYSTEM™ (RPS™) for quicker holeshots & maximized speed
12" (30.48 cm) adjustable jack plate—Black
Rigging tube for organized wiring & abrasion resistance
Stainless steel propeller
Construction & Exterior
100% composite deck core w/superior thermal stability & strength-to-weight ratio
Deck & hull chemically bonded & mechanically fastened w/stainless steel fasteners every 2" (5.08 cm)
Gelcoated stringer/liner system
Foam-filled hull for optimal buoyancy & safety
Full-width fiberglass-encapsulated composite transom
Low-profile gunnels to maximize deck size & for easier casting
NEW splashwell protective film
Integrated fold-down stainless steel reboarding ladder, angled for allowing optional shallow-water anchor
Electrical
Angled bow panel w/trolling motor receptacle, anchor/light switch, trim switch & capability to flush mount most 12" (30.5 cm) fishfinders
LED console courtesy light
Manual LED-lighted bow gear storage
Automotive-style labeled fuse panel w/cover
Interstate® cranking battery
2 heavy-duty Interstate® trolling batteries
NEW NOCO® GB40 jump starter pack
2-bank, 10-amp battery charger w/exterior receptacle
6-gauge trolling motor wiring w/50-amp circuit breaker
Master power switch
Waterproof Deutsch plugin gauge connectors
Water/abrasion-resistant connectors
Trailer
Custom-fit, tandem-axle steel NITRO® trailer
7-pin connector
14" (35.56 cm) custom aluminum wheels w/radial tires
Surge disc brakes on both axles
Hub system w/1-year limited warranty
Spare tire carrier w/matching spare
All-welded rectangular GALVASHIELD® frame
Space-saving swing-away tongue to reduce storage length
Fold-away tongue jack
Heavy-duty winch w/nylon strap & bow safety strap
Integrated winch stand step w/safety handle for easier boarding/reboarding at bow while boat is on trailer
Outboard motor support to reduce hull & transom stress while towing
Carpeted bunks & fender boards to protect hull
Submersible LED lights
Retractable transom tie downs
Safety cables
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
Price History
| Date | Event | Price |
|---|---|---|
| 1/28/26 | Initial price | $54,995 |
2023 Nitro Z20 Video Tours
Boattest.com Review
Overview
The Nitro Z20 is a tournament-level bass boat engineered to deliver rapid transit to fishing locations while providing amenities typically found on higher-end models. Designed with performance and angler functionality in mind, the Z20 offers a balance of speed, handling, and fishing features that appeal to serious bass anglers.
Power and Performance
The Z20 is available with either a standard Mercury 225 Pro XS four-stroke engine or an upgraded Mercury 250 Pro XS four-stroke, the latter fitted on our test boat with a manually adjustable 12-inch jack plate. Measuring 20 feet 2 inches in length with a 7 foot 10 inch beam and a hull draft of 16 inches, the boat's empty weight is approximately 2,000 pounds. During testing, with two passengers, 30 gallons of fuel, and equipment aboard, the estimated weight was 3,105 pounds. Powered by the 250-horsepower Mercury engine paired with a 14 by 24 inch stainless steel three-blade Fury propeller, the Z20 achieved a top speed of 76.6 miles per hour at 6,200 RPM. Its optimal cruising speed was 26.3 miles per hour at 3,000 RPM, delivering a fuel consumption of 5.3 gallons per hour and an effective range of 223 statute miles while maintaining a 10% fuel reserve from its 50-gallon capacity. Acceleration tests demonstrated rapid planing capabilities, reaching planing in 3.8 seconds, 20 mph in 5.3 seconds, and 30 mph in 7.7 seconds. The boat's mid-range acceleration is robust, providing a firm ride without water washing over the transom during deceleration. Handling characteristics reflect its bass boat design, with the hull climbing onto the pad quickly and maintaining precise line-holding in arcing turns, even over wakes and choppy water. The Nitro Vortex Technology (NVT) hull features six full-length parabolic strakes and a keel pad that enhances stability and smoothness at speed. Construction employs hand-laid fiberglass with reinforced layers in high-stress areas, a 100% composite chemically bonded transom, and a one-piece stringer grid molded integrally with some storage compartments for added space and strength.
Cockpit and Helm Features
The cockpit is equipped with twin Z-Core bucket seats featuring force flex suspension and contoured frames, designed in collaboration with professional angler Kevin Van Dam to provide comfort and support even at high speeds approaching 75 miles per hour. An optional second console is positioned forward of the port seat for anglers who prefer to fish alongside the driver at speed. This console includes a locking glove box with a 16 by 6 inch opening and convenient grab handles. The helm console is outfitted with V3 analog gauges, including a tachometer with integrated trim indicator, speedometer with fuel gauge, and instruments for water pressure and voltage. Standard electronics include a Lowrance Hook 2 5 fish finder, with options for additional devices. Controls are logically arranged with master power and ignition switches to the port of the tilt steering wheel, and a switch panel on the starboard side managing navigation and anchor lights, bilge pumps, and livewell functions. The stereo remote and conventional shift-throttle controls are located outboard on the starboard side. Hydraulic steering is standard, and optional upgrades include a foot throttle and turn signal-style trim switches to facilitate hands-on wheel control at high speeds.
Deck Layout and Fishing Amenities
Access to the forward casting deck is via steps located between the consoles, flanked by cup holders and tool racks. Beneath a hinged step lies a 62-quart cooler equipped with a removable wastebasket and sandwich tray. The bow casting deck spans 42.5 square feet and is covered with an anti-fatigue paddock mat. Bungee cords on each side secure rods during transit. Standard equipment includes a Minn Kota 24-volt trolling motor delivering 70 pounds of thrust with a 42-inch shaft. The bow panel accommodates optional fish finders up to 12 inches and houses switches for navigation lights and outboard trim. Additional features include tool racks, cup holders, and a trolling motor foot pedal. Storage is abundant with three lockable, gas-strut-assisted lockers: a port rod locker capable of holding ten rods up to eight feet long, a lighted center locker with removable dividers and integrated cup holders, and an open starboard locker with clips for paddles and a fire extinguisher. Four-inch pull-up cleats on each side facilitate docking and fender attachment.
Aft Deck and Livewell System
The aft fishing deck measures 82 inches wide by 46 inches fore to aft and includes a 22-inch wide step between the cockpit seats. Under a non-skid hatch is a shallow storage tray, with additional storage for nets above the seats and a removable catch ruler integrated into the deck. A boarding ladder folds neatly into the aft port corner, complemented by a padded grab handle. Four hatches in the aft deck provide access to twin 19-gallon Guardian livewells featuring digital timers, 750-gallon power pumps, a recirculating system, and rounded corners for fish safety. Removable tubs with slots for seven Plano 3700 tackle trays flank the livewells. Behind these, a large hatch grants access to the battery switch, charger, and mechanical components. The electrical system includes dual trolling batteries and a dedicated engine start battery. A hinged panel reveals bilge and livewell pumps, and a removable tray above the batteries offers additional storage.
Trailer and Final Assessment
The Nitro Z20 is delivered on a custom-made trailer featuring a swing-away tongue for ease of transport and storage. Overall, the Z20 presents as a tournament-quality bass boat that combines strong performance with thoughtfully integrated fishing amenities. The incorporation of the new Mercury four-stroke outboard maintains its competitive edge in speed and handling, making it a compelling choice for serious anglers seeking a balance of power, comfort, and functionality.
Overview from around the web 2023 Nitro Z20
Customers are praising the 2023 Nitro Z20 for its exceptional performance and versatility on the water
Many highlight its powerful engine options and smooth handling, making it ideal for both fishing and cruising. The spacious and well-designed deck layout receives positive feedback for comfort and convenience during long days on the lake. Anglers appreciate the advanced fishing features, including ample storage, quality rod holders, and high-tech fish-finding equipment. Overall, owners commend the Nitro Z20 for combining durability, style, and functionality in a competitive package.
The Biggest Pros and Cons
The 2023 Nitro Z20 offers a range of features that make it a top choice for bass fishing enthusiasts. Here are some of the pros and cons to consider:
Pros
Advanced Hull Design: The Z20 features a sleek, performance-oriented hull that provides excellent stability and smooth handling, even in choppy water.
Powerful Engine Options: Equipped with high-performance Mercury engines, the Z20 delivers impressive speed and acceleration for quick access to fishing spots.
Spacious Deck Layout: Ample deck space with well-placed storage compartments allows for organized gear and comfortable movement.
Cutting-Edge Electronics: Comes standard with modern fish-finding and navigation systems, enhancing your fishing experience.
Durable Construction: Built with high-quality materials, the boat offers long-lasting durability and reliability.
Cons
Price Point: As a premium bass boat, the Z20 may be on the higher end of the price spectrum, which could be a consideration for budget-conscious buyers.
Fuel Consumption: With powerful engine options, fuel efficiency might be lower compared to smaller or less powerful boats.
Learning Curve: For beginners, handling the advanced features and performance capabilities of the Z20 might require some time to get accustomed to.
Made For
The 2023 Nitro Z20 is designed for serious anglers who demand top-tier performance on the water. Ideal for tournament fishermen and avid bass enthusiasts, this boat offers advanced features, cutting-edge technology, and superior handling to help you fish with confidence and precision. Whether you're chasing trophy bass or exploring new fishing spots, the Nitro Z20 delivers the power, speed, and reliability you need to elevate your fishing game.
