2027 MasterCraft X24 Boat in Mooresville, NC 28117 US
Built in 2027
X24
1 Engine (Ilmor)
24 feet
Gas
Fiberglass/Reinforced
2027 MasterCraft X24 | Ilmor 6.2L GDI VD 2.1 | Z9 Power Tower | Proportional Stern Thruster | SurfStar | Midnight Black / Starlight White Flake | Fully Loaded
Experience the pinnacle of MasterCraft performance, luxury, and innovation with this 2027 MasterCraft X24.
This stunning X24 is finished in an unmistakable Midnight Black and Starlight White Flake exterior with Gold Satin accents, complemented by a sophisticated Coolfeel Beach Tan and Jet Black interior. From the water, the combination delivers a head-turning presence that perfectly matches the X24's premium status.
Underneath the styling is serious performance. The Ilmor 6.2L GDI VD 2.1 provides the power to take full advantage of MasterCraft's advanced watersports systems, while the SurfStar System uses electric-over-hydraulic actuators, side-to-side switching, and wake-shaping devices to create a highly customizable surf experience.
One of the standout features on this X24 is the Proportional Stern Thruster, providing enhanced low-speed maneuverability and making docking and positioning the boat significantly easier.
PERFORMANCE & TECHNOLOGY- Ilmor 6.2L GDI VD 2.1
- Proportional Stern Thruster
- SurfStar System - Electric Over Hydraulic Actuators
- SurfStar Side-to-Side Switching
- SurfStar Wake-Shaping Devices
- FastFill Ballast
- Attitude Adjustment Plate
- Tracking Fins
- 15" Center Touchscreen
- 12" Touchscreen
- MyDrive Encoder
- Navigation Maps
- Depth Finder
- Telematics
- Z9 Power Tower with Standard Bimini
- Z9 SoundPods - Black with 2-Channel Amplifier
- Activ-View Panoramic
- Billet Walkthrough Door
- Pop-Up Cleats
- Fender Clips
- Anchor
This X24 is equipped to keep everyone comfortable whether you're spending an afternoon surfing or enjoying a cooler day on the lake.
- Heated Seats
- Heater
- Bow Filler Cushion
- Premium Coolfeel Beach Tan Interior
- Coolfeel Jet Black Trim
- SeaDek - Dune over Cappuccino
- Smart Battery Charger - Multi-Chemistry, 110V
- Over-Tower Boat Cover
- Transom Remote
The X24's upgraded SoundStage audio system provides an impressive sound experience throughout the boat.
- SoundStage Cockpit Audio
- Meridian Digital Signal Processor with Zone Control
- Two 12" Subwoofers
- Four 8.5" Cockpit Speakers
- Two 8.5" Bow Speakers
- Two 7" Dash Speakers
- One 8-Channel Amplifier
- One 2-Channel Amplifier
- Bluetooth & Radio Controls
- RGB Lighting Package
- Underwater Lights
- Docking Lights
Midnight Black / Starlight White Flake / Gold Satin
- Midnight Black Deck Exterior
- Starlight White Flake Hull
- Midnight Black Hull Bottom
- Midnight Black Transom
- Midnight Black Hull Wrap
- Gold Satin Exterior Metal Accents
- Gold Satin Side Strake
- Midnight Black Z9 Power Tower
- Midnight Black Windshield
- Midnight Black Swim Platform
Coolfeel Beach Tan / Jet Black
- Coolfeel Beach Tan Primary, Secondary & Accent
- Coolfeel Jet Black Trim
- White Pleat Stitch Thread
- Black Top Stitch
- Dune over Cappuccino SeaDek
- Midnight Black Monograms
The MasterCraft X24 is designed for the boater who refuses to compromise. With its expansive layout, sophisticated styling, powerful Ilmor engine, advanced SurfStar technology, premium Z9 Power Tower, and exceptional collection of comfort and convenience features, the X24 delivers a true flagship-level experience on the water.
Whether your day consists of perfecting your surf wave, entertaining a crowd, cruising the lake, or enjoying a sunset with family and friends, this X24 is equipped to make every moment exceptional.
And with the Proportional Stern Thruster, docking and maneuvering this premium 24-foot boat is easier and more controlled than ever.
Factory-configured total price: $392,766.67
Boat Serial Number: US MBCPJBB0H627
Contact Dyer Marine in Mooresville, NC today for pricing, availability, additional information, or to schedule a private showing of this exceptional 2027 MasterCraft X24.
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
Price History
| Date | Event | Price |
|---|---|---|
| 8/29/26 | Initial price | $392,766 |
MasterCraft X24: BoatTEST Review
Overview
The Mastercraft X-24 is a premium towboat that represents the first model in the company's redesigned X-Series, evolving from the award-winning X-23. This new series features a comprehensive overhaul in terms of features, functionality, hull design, and wake performance, aiming to deliver versatile wave characteristics suitable for both elite athletes and beginners.
Wake and Ballast System
Central to the X-24's performance is its advanced Gen 2 surf system, which includes a six-ballast fast fill configuration. This system comprises one forward hard ballast tank, two aft hard tanks, two aft bags positioned above those tanks, and an innovative switchback tank that enables lateral ballast distribution for symmetrical wake formation. The ballast is managed by seven Johnson pumps, each capable of pumping 30 gallons per minute, allowing the boat to add approximately 4,300 pounds of ballast in under four minutes. Adjustable surf tabs at the stern control the wake profile, with independent left and right settings and a central attitude adjustment tab to manage bow rise, compensating for internal weight variations. All ballast and surf settings, along with GPS speed, are controlled via a seven-inch touchscreen at the helm, allowing operators to select from factory presets or customize wake parameters for specific riders with ease.
Power and Performance
The X-24 is powered by a single 430-horsepower Ilmor 6.2-liter GDI V8 engine. Its dimensions include a length overall of 26.2 feet, a beam of 8 feet 6 inches, and a draft of 2 feet 6 inches. The hull geometry has been refined to provide a deeper water entry, enhancing wake size. Performance testing revealed an endurance ranging from approximately 6.9 hours at 21.8 miles per hour (3,500 RPM) to 13.2 hours at 10.6 miles per hour (2,500 RPM). The top speed recorded was 38.2 miles per hour at 5,600 RPM, with the most economical cruising speed at 27 miles per hour (4,000 RPM). Acceleration was brisk, with a time to plane of 3.2 seconds, 0 to 20 mph in 4.8 seconds, and 0 to 30 mph in 7.2 seconds. Handling was responsive and smooth, with a three and a half turn lock-to-lock steering ratio and a 16-inch rudder, providing stable and predictable maneuvering even with full ballast.
Exterior Design and Deck Layout
The X-24 features a U-shaped bow finished in a tritone color scheme, complementing its modern aesthetic. The cockpit and deck areas continue the tri-tone vinyl upholstery theme with custom hand-stitching unique to the X-Series. Seating is abundant and versatile, accommodating up to 18 passengers with forward-facing chaise seats at the bow and wraparound corner seats in the cockpit that convert to aft-facing chaise lounges. Storage is ample, including a 62-inch compartment under the port-side seating for longer boards and a 36-quart cooler beneath the starboard bench. The cockpit flooring options include C-deck or color-matched decadence flooring. The swim platform is also C-deck treated and features built-in handholds and a 22-inch retractable swim ladder for easy water access. The premium tower includes an integrated bimini, two hanging speakers, clamping board racks, and a center tow pylon, with an optional camera mount available.
Helm and Controls
The helm is positioned to starboard and features a vinyl-wrapped dash with a tilt-mounted steering wheel. Instrumentation includes recessed analog gauges set in billet aluminum, complemented by a 7-inch touchscreen interface for controlling ballast, surf settings, and other boat functions. Manual switches provide redundancy in case of touchscreen failure. Additional helm amenities include a phone holder, drink holders, engine key, and shifter. The main battery shutoff and breaker panel are conveniently located to the left of the helm. The boat incorporates Mastercraft's BTS windshield design, favored by water sport enthusiasts for improved communication with individuals in the water and ease of docking. The windshield sides are rounded and finished with aluminum billets that double as grab handles, and a securely fitting wind dam is included.
Interior and Storage Features
The interior layout maximizes space through a pickle fork design, providing larger seating areas and storage compartments. Forward compartments include dedicated anchor storage, while the cockpit houses multiple storage areas beneath seating. The top storage locker creatively functions as a personal flotation device warmer by utilizing engine heat. The aft-facing bench converts into a spotter seat or a large lounging area with an optional filler cushion, and a tow pylon can be installed in this area. Additional storage and utility spaces beneath companion seating accommodate batteries, a fire extinguisher, a trash receptacle, and the tow pylon base.
Conclusion
The Mastercraft X-24 is a thoughtfully engineered towboat that blends advanced ballast and wake-shaping technologies with refined power and handling characteristics. Its versatile wake profiles cater to a wide range of water sport enthusiasts, from beginners to professional athletes. The spacious and well-appointed interior, combined with practical storage solutions and premium exterior features, make the X-24 well-suited for extended days on the water. Overall, it delivers a compelling package for those seeking high performance and comfort in a modern towboat.
