2020 MasterCraft X24 Boat in Boynton Beach, FL 33435 US
Built in 2020
X24
1 Engine (Ilmor)
24.2 feet
Gas
Fiberglass/Reinforced
Command the surf with the machine that was named most innovative product by the National Marine Manufacturers Association. The X24 is the new generation of surf performance, and the ultimate way to make waves. Starting with 4300 pounds of ballast, you will be blown away at the ease of use and epic waves and wakes. The high performance Switchback Ballast Tank lets you transfer waves and riders effortlessly and instantly, and optional FastFill high speed ballast pumps will have you surfing the most adjustable waves in the industry in under 4 minutes and one push of a button. The Gen 2 Surf System is the ultimate combination of easy profiles, wave customization, and performance-so everyone on board can catch the perfect swell.
Price History
| Date | Event | Price |
|---|---|---|
| 7/10/26 | Price decreased | $125,000(-7.4%) |
| 7/2/26 | Initial price | $135,000 |
2020 MasterCraft X24 Video Tours
MasterCraft X24: BoatTEST Review
Overview
The Mastercraft X-24 is a premium towboat that represents the first model in the company's redesigned X-Series, evolving from the award-winning X-23. This new series features a comprehensive overhaul in terms of features, functionality, hull design, and wake performance, aiming to deliver versatile wave characteristics suitable for both elite athletes and beginners.
Wake and Ballast System
Central to the X-24's performance is its advanced Gen 2 surf system, which includes a six-ballast fast fill configuration. This system comprises one forward hard ballast tank, two aft hard tanks, two aft bags positioned above those tanks, and an innovative switchback tank that enables lateral ballast distribution for symmetrical wake formation. The ballast is managed by seven Johnson pumps, each capable of pumping 30 gallons per minute, allowing the boat to add approximately 4,300 pounds of ballast in under four minutes. Adjustable surf tabs at the stern control the wake profile, with independent left and right settings and a central attitude adjustment tab to manage bow rise, compensating for internal weight variations. All ballast and surf settings, along with GPS speed, are controlled via a seven-inch touchscreen at the helm, allowing operators to select from factory presets or customize wake parameters for specific riders with ease.
Power and Performance
The X-24 is powered by a single 430-horsepower Ilmor 6.2-liter GDI V8 engine. Its dimensions include a length overall of 26.2 feet, a beam of 8 feet 6 inches, and a draft of 2 feet 6 inches. The hull geometry has been refined to provide a deeper water entry, enhancing wake size. Performance testing revealed an endurance ranging from approximately 6.9 hours at 21.8 miles per hour (3,500 RPM) to 13.2 hours at 10.6 miles per hour (2,500 RPM). The top speed recorded was 38.2 miles per hour at 5,600 RPM, with the most economical cruising speed at 27 miles per hour (4,000 RPM). Acceleration was brisk, with a time to plane of 3.2 seconds, 0 to 20 mph in 4.8 seconds, and 0 to 30 mph in 7.2 seconds. Handling was responsive and smooth, with a three and a half turn lock-to-lock steering ratio and a 16-inch rudder, providing stable and predictable maneuvering even with full ballast.
Exterior Design and Deck Layout
The X-24 features a U-shaped bow finished in a tritone color scheme, complementing its modern aesthetic. The cockpit and deck areas continue the tri-tone vinyl upholstery theme with custom hand-stitching unique to the X-Series. Seating is abundant and versatile, accommodating up to 18 passengers with forward-facing chaise seats at the bow and wraparound corner seats in the cockpit that convert to aft-facing chaise lounges. Storage is ample, including a 62-inch compartment under the port-side seating for longer boards and a 36-quart cooler beneath the starboard bench. The cockpit flooring options include C-deck or color-matched decadence flooring. The swim platform is also C-deck treated and features built-in handholds and a 22-inch retractable swim ladder for easy water access. The premium tower includes an integrated bimini, two hanging speakers, clamping board racks, and a center tow pylon, with an optional camera mount available.
Helm and Controls
The helm is positioned to starboard and features a vinyl-wrapped dash with a tilt-mounted steering wheel. Instrumentation includes recessed analog gauges set in billet aluminum, complemented by a 7-inch touchscreen interface for controlling ballast, surf settings, and other boat functions. Manual switches provide redundancy in case of touchscreen failure. Additional helm amenities include a phone holder, drink holders, engine key, and shifter. The main battery shutoff and breaker panel are conveniently located to the left of the helm. The boat incorporates Mastercraft's BTS windshield design, favored by water sport enthusiasts for improved communication with individuals in the water and ease of docking. The windshield sides are rounded and finished with aluminum billets that double as grab handles, and a securely fitting wind dam is included.
Interior and Storage Features
The interior layout maximizes space through a pickle fork design, providing larger seating areas and storage compartments. Forward compartments include dedicated anchor storage, while the cockpit houses multiple storage areas beneath seating. The top storage locker creatively functions as a personal flotation device warmer by utilizing engine heat. The aft-facing bench converts into a spotter seat or a large lounging area with an optional filler cushion, and a tow pylon can be installed in this area. Additional storage and utility spaces beneath companion seating accommodate batteries, a fire extinguisher, a trash receptacle, and the tow pylon base.
Conclusion
The Mastercraft X-24 is a thoughtfully engineered towboat that blends advanced ballast and wake-shaping technologies with refined power and handling characteristics. Its versatile wake profiles cater to a wide range of water sport enthusiasts, from beginners to professional athletes. The spacious and well-appointed interior, combined with practical storage solutions and premium exterior features, make the X-24 well-suited for extended days on the water. Overall, it delivers a compelling package for those seeking high performance and comfort in a modern towboat.
Overview from around the web 2020 MasterCraft X24
The 2020 MasterCraft X24 has garnered rave reviews from customers who appreciate its blend of performance, comfort, and advanced technology
Enthusiasts praise its impressive wake and waves, making it a favorite for both wakeboarding and surfing. Users highlight the customizable ballast system, which allows for optimal weight distribution and an exceptional on-water experience. Customers also admire the spacious interior, noting that it comfortably accommodates family and friends with ample seating and storage options. The luxurious finishes and high-quality materials contribute to its upscale feel, making every outing a pleasure. Tech-savvy users appreciate the intuitive touchscreen controls and advanced sound system, which enhance entertainment on the water. Many testimonials emphasize the smooth ride and handling, ensuring a thrilling yet safe experience. Overall, the 2020 MasterCraft X24 is celebrated as a top-tier boat that excels in performance while providing luxury and versatility for water sports enthusiasts.
Made For
The 2020 MasterCraft X24 is designed for passionate watersport enthusiasts and families seeking the ultimate experience on the water. With its spacious layout, this boat caters to those who love to wakeboard, waterski, or simply cruise in style and comfort. Whether you're a seasoned pro or just starting out, the X24’s advanced features and performance capabilities make it suitable for all skill levels. This model is perfect for families who value both adventure and relaxation, offering luxurious seating for up to 18 passengers, plenty of storage for gear, and a premium sound system to keep the energy high. The X24's versatility shines through its customizable wake settings, allowing users to dial in the perfect wake for any rider's preference. With its sleek design and cutting-edge technology, the 2020 MasterCraft X24 appeals to those who appreciate both aesthetics and performance, making it an ideal choice for anyone looking to elevate their time on the water.
Finance your dream boat!
Finance your dream boat!
Be the first to know when similar boats hit the market
Get notified when new boats become available
Boats For Sale in Florida, United States Similar to the 2020 MasterCraft X24
Compare with similar boats and find the perfect one for you.
 2020 MasterCraft X24 | |||||
|---|---|---|---|---|---|
| $125,000 | $124,000 | $129,900 | $119,900 | $114,900 | $139,900 |
| Boynton Beach | Boynton Beach | Orlando | Polk City | Homestead | Fort Lauderdale |
| 24' | 23' | 24' | 22' | 24' | 24' |
| 3' | - | - | - | - | - |
| Ilmor | Ilmor | Ilmor 6.2 430 HP | - | Imo | Ilmor |
| 430 hp | 365 hp | 430 hp | - | 430 hp | 430 hp |
| 24 | 10 | 269 | 19 | 332 | 50 |
