2023 Sun Tracker Party Barge 22 XP3
$63,180
Boat in Mooresville, NC 28117 US
Built in 2023
Party Barge 22 XP3
1 Engine (MERCURY MARINE)
24.2 feet
--
Aluminum
The PARTY BARGE® 22 XP3 is a recreational pontoon through and through.
It offers everything from four lounge seats (with our STOW MORE™ seat storage system) to the new 10' Bimini top to swim platform to the new stereo and more. All that, combined with things like three inward-swinging gates, padded woven flooring and cooler storage, ensures this pontoon boat is ready for a full day of fun.
Then, it adds in the XP3 performance package, which includes three 26" pontoon logs with lifting strakes, underpinning and hydraulic steering to raise the horsepower rating to 200 and provide the performance needed for tubing and cruising! The XP3 package also includes in-deck storage, perfect for stowing watersports gear.
-
Length:24' 2"
-
Deck Length: 22' 1"
-
Deck Width: 8' 6"
-
Max. Recommended HP: 200 HP
-
Fuel Capacity: 52 gal.
-
Pontoon Log Length: 22' 3"
-
Pontoon Log Diameter: 26"
-
Pontoon Log Material: 0.1 5052 marine alloy
-
Max. Person Capacity: 11 persons
-
Max. Person Weight: 1600 lbs.
-
Max. Person, Motor & Gear Weight: 2400 lbs.
-
Interior Depth: 29.5"
-
Average Dry Weight: 2980 lbs.
-
Average Package Weight: 4975 lbs.
-
Package Height: 8' 11"
-
Package Width: 8' 6"
-
Towing Length: 32' 4"
-
Storage Length: 32' 4"
Comfort, Convenience & Peace of Mind
-
10+LIFE™ Limited Lifetime Warranty
-
NMMA® certified
-
10' (3.05 m) SureShade® powered Bimini top w/push-button stow & deploy, LED courtesy lights & protective boot (Bimini top will be Black w/Charcoal fencing & will be Sand w/Copper Red fencing)
-
Storage pockets in Bimini top
-
Nylon gate latches & heavy-duty hinges that open inward
-
Port & starboard LED navigation lights
-
Bimini-mounted anchor/navigation light
-
Mooring eye on starboard side for tie off
-
Four 4.5" (11.43 cm) fold-down mooring cleats
-
Motor-stop safety lanyard
-
Fire extinguisher
-
Horn
Console
-
Deluxe soft-touch sport steering wheel
-
Tilt hydraulic steering
-
Wraparound sport shroud & tinted, removable windscreen
-
Below-console cooler/storage space w/door & integrated pouch
-
Small items tray
-
Drink holders
-
Built-in footrest w/non-skid pad
-
AM/FM Bluetooth®-capable stereo head unit w/integrated low voltage alarm & 2 NEW upholstery speakers
-
USB/3.5 mm auxiliary input ports on console for direct stereo connection
-
Tachometer, trim meter/speedometer & fuel & hour gauges
-
Lighted rocker switches w/bilge switch
-
Ergonomically positioned Mercury® binnacle control box w/trim
-
12V outlet
-
Dark console color
Interior
-
The patented STOW MORE™ system features an added compartment in the seat back for increased storage
-
Bow port couch w/STOW MORE™ system, underseat storage & armrest w/drink holder
-
Bow starboard couch w/STOW MORE™ system & underseat storage
-
88" (2.24 m) long, 23" (58.42 cm) deep lighted in-floor storage compartment w/bilge pump in center log & NEW spaghetti mat
-
High-back swiveling port bucket seat, reclining & w/self-leveling arms
-
High-back swiveling helm bucket seat, reclining & w/self-leveling arms
-
Aft port couch w/STOW MORE™ system, underseat storage & arm
-
Aft starboard couch w/STOW MORE™ system, lockable underseat storage & arm
-
Midship port side drink holder
-
Full-width aft swim deck
-
Receptacle for optional ski tow pylon
-
Woven 16-oz. (.45 kg) marine-grade flooring throughout
-
Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
-
2 movable drink holders/armrests
-
Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
Performance
-
XP3 performance package – strakes on inboard side of outer logs & both sides of center tube
-
Nose cone & motor pod wave/spray deflectors for a drier ride
-
Factory-matched aluminum propeller
Construction & Exterior
-
Color: NEW Charcoal or Copper Red fencing
-
Exterior styling w/XP3 graphics package
-
Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
-
Rotomolded couches & backs for furniture w/Diamante Pepper accent
-
Heavy-duty bow U-channel reinforcement behind deck trim
-
Three 26" (66.04 cm) diameter XP3 high-performance multichambered pontoon logs w/welded-on lifting strakes & internal bracing for additional strength
-
1-piece full-length M-bracket deck supports
-
Protective exoskeleton rail & panel system for durability & a quieter ride
-
High-sheen fence finish for long-lasting good looks
-
1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/decorative styling
-
Reinforced bow & stern structures
-
Factory-installed underpinning (under-deck shielding) for improved performance
-
Extruded anodized aluminum deck edging w/polished aft corner covers
-
All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
-
Stainless or coated corrosion-resistant fasteners
-
Pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
-
Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
-
Elevated fence panels for deck drainage & ventilation
-
Sound- & vibration-deadening fence insulation for a quiet ride
-
Box-beam all-aluminum transom for strength & longevity
-
Port wheelchair-access gate
-
Rear boarding platform w/NEW 4-step telescoping boarding ladder & grab rails
Electrical
-
500 GPH (1892.71 LPH) Ultima auto bilge pump
-
Interior courtesy lighting
-
Battery disconnect switch
-
Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
-
Protective abrasion-resistant wire wrap
-
Water-resistant connectors
Price History
| Date | Event | Price |
|---|---|---|
| 6/28/25 | Initial price | $63,180 |
2023 Sun Tracker Party Barge 22 XP3 Video Tours
Boattest.com Review
Overview
The SunTracker Party Barge 22XP3 is a pontoon boat designed primarily for recreational enjoyment and social gatherings on the water. It features a spacious layout capable of comfortably accommodating up to ten people, with thoughtful design elements aimed at enhancing accessibility, comfort, and entertainment.
Exterior Design and Deck Layout
This model offers three access points: an 18-inch wide entry at the aft, a 24-inch bow entry, and a notably wide 32-inch port side access suitable for wheelchair users. The railings stand at a standard height of 26 inches, ensuring safety throughout the deck. The aft door is angled to extend deck space near the reboarding ladder, while the engine is mounted on a separate pod that also houses the fuel tank and provides two side steps for convenient and safe engine maintenance. The aft sun deck is padded for comfort and overlooks the swim platform, allowing occupants to remain engaged with water activities. A unique feature is the pop-up changing room beneath the sun pad, which opens easily to provide a private space for changing out of wet swimwear. Additional storage is available under the sun pad, where the battery is securely housed.
Seating and Entertainment Areas
Forward of the helm, the boat includes an L-shaped lounger on the port side with rotocast molded storage compartments beneath the seats, including a lockable aluminum-covered storage area that is compartmentalized for organization. The helm console offers open storage space suitable for a cooler, though securing rails would be beneficial to prevent movement underway. Entertainment is provided by a Jensen AM-FM stereo system with MP3 jack, Bluetooth connectivity, and four directional speakers, allowing guests to enjoy music while swimming or relaxing on the stern. The helm itself is a single fiberglass module with a faux burl wood gauge panel featuring three chrome-bezeled gauges. The hydraulic steering wheel is tilt-adjustable, and the engine control is mounted vertically. The captain’s seat includes flip-up armrests and a pedestal mount that allows swiveling to join conversations in the adjacent L-shaped seating. Further forward, two large couches face each other port and starboard, upholstered in UV-resistant vinyl with soft, multi-density foam cushions. A pedestal table can be positioned between these couches to create an intimate gathering space. The deck is covered with sculptured marine-grade carpet, with an optional vinyl cockpit flooring available. A color-keyed 9-foot polyester BEMEDE top with LED courtesy lights provides full sun protection.
Power and Performance
The Party Barge 22XP3 measures 22 feet 2 inches in length overall with a beam of 8 feet 6 inches. It has an empty weight of 2,840 pounds, and with fuel, two passengers, and test power, the test weight was approximately 3,835 pounds. Powered by a 150-horsepower Mercury four-stroke engine turning a 15x15 inertia propeller, the boat achieved a top speed of 38.7 miles per hour at 5,600 rpm while consuming 14.2 gallons per hour, resulting in an 86-mile range at top speed. The most efficient cruising speed was found at 3,000 rpm, delivering 17.3 miles per hour with a fuel burn of 3.85 gallons per hour. At this pace, the boat could run for over eight hours covering 141 miles with a 10% fuel reserve. Acceleration was brisk, with the boat planing in 2.6 seconds, reaching 20 mph in 4.7 seconds, and exceeding 30 mph in 8.6 seconds. The vessel accelerates from a level attitude, and trimming the bow upward optimizes cruising economy and ride comfort. This trim adjustment also contributes to a dry ride by effectively handling waves. The boat maintains a flat attitude during slow turns and leans slightly into performance turns, responding well to helm inputs with a small, consistent turning radius. Power adjustments near docking do not cause the stern to swing excessively, and the boat settles back to a level attitude when power is reduced.
Conclusion
The SunTracker Party Barge 22XP3 is a well-designed pontoon boat that maximizes its 8-foot 6-inch beam to provide a spacious, comfortable, and versatile entertainment platform. Its accessibility features, ample storage, and thoughtful seating arrangements make it suitable for social outings on the water. The performance characteristics, including efficient cruising, quick acceleration, and stable handling, complement its recreational focus. Overall, the Party Barge 22XP3 offers a balanced combination of comfort, functionality, and enjoyable performance for casual boating enthusiasts.
Overview from around the web 2023 Sun Tracker Party Barge 22 XP3
Customers are praising the 2023 Sun Tracker Party Barge 22 XP3 for its spacious and comfortable design, making it perfect for gatherings and family outings on the water
Many appreciate its sturdy build and smooth handling, which provide a safe and enjoyable ride. The boat’s modern features and ample seating make it ideal for entertaining, while the reliable engine ensures consistent performance. Overall, owners highlight the Party Barge 22 XP3 as a versatile and fun pontoon that delivers great value for its price.
The Biggest Pros and Cons
The 2023 Sun Tracker Party Barge 22 XP3 offers a blend of comfort, performance, and versatility, making it a popular choice for boating enthusiasts. Here are some pros and cons to consider:
Pros
Spacious Layout: The 22-foot deck provides ample seating and room for entertaining family and friends.
Durable Construction: Built with high-quality materials, ensuring longevity and resistance to wear.
Powerful Performance: Equipped with a reliable outboard engine that delivers smooth and efficient cruising.
Comfort Features: Includes plush seating, a bimini top for shade, and convenient storage compartments.
Versatility: Suitable for various water activities such as cruising, fishing, and watersports.
Cons
Fuel Efficiency: Depending on the engine choice, fuel consumption may be higher compared to smaller pontoons.
Maneuverability: Larger size might make docking and tight turns a bit challenging for novice boaters.
Storage Limitations: While storage is adequate, extended trips may require additional planning for gear.
Price Point: As a feature-rich model, it may be priced higher than more basic pontoons in the market.
Made For
The 2023 Sun Tracker Party Barge 22 XP3 is perfect for families and friends who love spending time on the water in style and comfort. Designed for those who enjoy leisurely cruises, social gatherings, and outdoor fun, this pontoon boat offers spacious seating, ample storage, and a smooth, stable ride. Whether you're hosting a relaxing day on the lake or celebrating special occasions, the Party Barge 22 XP3 provides a versatile and enjoyable boating experience for everyone on board.
