2023 Sun Tracker Party Barge 22 XP3 Boat in Denver, CO 80238 US
Built in 2023
Party Barge 22 XP3
1 Engine (MERCURY MARINE)
24.2 feet
--
Aluminum
The PARTY BARGE® 22 XP3 is a recreational pontoon through and through.
It offers everything from four lounge seats (with our STOW MORE™ seat storage system) to the new 10' Bimini top to swim platform to the new stereo and more. All that, combined with things like three inward-swinging gates, padded woven flooring and cooler storage, ensures this pontoon boat is ready for a full day of fun.
Then, it adds in the XP3 performance package, which includes three 26" pontoon logs with lifting strakes, underpinning and hydraulic steering to raise the horsepower rating to 200 and provide the performance needed for tubing and cruising! The XP3 package also includes in-deck storage, perfect for stowing watersports gear.
Length:24' 2"
Deck Length: 22' 1"
Deck Width: 8' 6"
Max. Recommended HP: 200 HP
Fuel Capacity: 52 gal.
Pontoon Log Length: 22' 3"
Pontoon Log Diameter: 26"
Pontoon Log Material: 0.1 5052 marine alloy
Max. Person Capacity: 11 persons
Max. Person Weight: 1600 lbs.
Max. Person, Motor & Gear Weight: 2400 lbs.
Interior Depth: 29.5"
Average Dry Weight: 2980 lbs.
Average Package Weight: 4975 lbs.
Package Height: 8' 11"
Package Width: 8' 6"
Towing Length: 32' 4"
Storage Length: 32' 4"
Comfort, Convenience & Peace of Mind
10+LIFE™ Limited Lifetime Warranty
NMMA® certified
10' (3.05 m) SureShade® powered Bimini top w/push-button stow & deploy, LED courtesy lights & protective boot (Bimini top will be Black w/Charcoal fencing & will be Sand w/Copper Red fencing)
Storage pockets in Bimini top
Nylon gate latches & heavy-duty hinges that open inward
Port & starboard LED navigation lights
Bimini-mounted anchor/navigation light
Mooring eye on starboard side for tie off
Four 4.5" (11.43 cm) fold-down mooring cleats
Motor-stop safety lanyard
Fire extinguisher
Horn
Console
Deluxe soft-touch sport steering wheel
Tilt hydraulic steering
Wraparound sport shroud & tinted, removable windscreen
Below-console cooler/storage space w/door & integrated pouch
Small items tray
Drink holders
Built-in footrest w/non-skid pad
AM/FM Bluetooth®-capable stereo head unit w/integrated low voltage alarm & 4 upholstery speakers
USB/3.5 mm auxiliary input ports on console for direct stereo connection
Tachometer, trim meter/speedometer & fuel & hour gauges
Lighted rocker switches w/bilge switch
Ergonomically positioned Mercury® binnacle control box w/trim
12V outlet
Dark console color
Interior
The patented STOW MORE™ system features an added compartment in the seat back for increased storage
Bow port couch w/STOW MORE™ system, underseat storage & armrest w/drink holder
Bow starboard couch w/STOW MORE™ system & underseat storage
88" (2.24 m) long, 23" (58.42 cm) deep lighted in-floor storage compartment w/bilge pump in center log & NEW spaghetti mat
High-back swiveling port bucket seat, reclining & w/self-leveling arms
High-back swiveling helm bucket seat, reclining & w/self-leveling arms
Aft port couch w/STOW MORE™ system, underseat storage & arm
Aft starboard couch w/STOW MORE™ system, lockable underseat storage & arm
Midship port side drink holder
Full-width aft swim deck
Receptacle for optional ski tow pylon
Woven 16-oz. (.45 kg) marine-grade flooring throughout
Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
2 movable drink holders/armrests
Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
Performance
XP3 performance package – strakes on inboard side of outer logs & both sides of center tube
Nose cone & motor pod wave/spray deflectors for a drier ride
Factory-matched aluminum propeller
Construction & Exterior
Color: NEW Charcoal or Copper Red fencing
Exterior styling w/XP3 graphics package
Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
Rotomolded couches & backs for furniture w/Diamante Pepper accent
Heavy-duty bow U-channel reinforcement behind deck trim
Three 26" (66.04 cm) diameter XP3 high-performance multichambered pontoon logs w/welded-on lifting strakes & internal bracing for additional strength
1-piece full-length M-bracket deck supports
Protective exoskeleton rail & panel system for durability & a quieter ride
High-sheen fence finish for long-lasting good looks
1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/decorative styling
Reinforced bow & stern structures
Factory-installed underpinning (under-deck shielding) for improved performance
Extruded anodized aluminum deck edging w/polished aft corner covers
All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
Stainless or coated corrosion-resistant fasteners
Pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
Elevated fence panels for deck drainage & ventilation
Sound- & vibration-deadening fence insulation for a quiet ride
Box-beam all-aluminum transom for strength & longevity
Port wheelchair-access gate
Rear boarding platform w/NEW 4-step telescoping boarding ladder & grab rails
Electrical
500 GPH (1892.71 LPH) Ultima auto bilge pump
Interior courtesy lighting
Battery disconnect switch
Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
Protective abrasion-resistant wire wrap
Water-resistant connectors
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice. All sales are final. No returns accepted.
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice. All sales are final. No returns accepted.
Price History
| Date | Event | Price |
|---|---|---|
| 6/28/25 | Initial price | $56,699 |
Boattest.com Review
Overview
The SunTracker Party Barge 22XP3 is a pontoon boat designed primarily for social enjoyment and recreational activities on the water. It offers spacious accommodations and thoughtful features aimed at maximizing comfort and convenience for up to 10 passengers. This model emphasizes accessibility, entertainment, and ease of handling, making it a versatile platform for gatherings and leisurely cruising.
Exterior Design and Deck Layout
The Party Barge 22XP3 features three access points to facilitate boarding: an 18-inch wide entry at the aft, a 24-inch bow entry, and a notably wide 32-inch port side entry suitable for wheelchair access. The railings stand at a standard height of 26 inches, ensuring safety without obstructing views. The aft door is uniquely angled to extend deck space near the reboarding ladder. The engine is mounted on a separate pod that also houses the fuel tank, with two side steps providing a secure area for engine maintenance and daily checks. A padded aft sun deck offers a comfortable spot to relax while remaining engaged with activities on the swim platform and in the water. Beneath this sun pad is a pop-up changing room, spacious enough for changing out of wet swimwear, which opens easily and secures with a latch. Additionally, lifting this section reveals a well-secured battery and extra storage space.
Seating and Entertainment Areas
Forward of the helm, the boat provides two primary gathering areas. To port, an L-shaped lounger includes rotocast molded storage compartments beneath each seat and a lockable aluminum-covered storage box with internal compartments. The helm console offers open storage space beneath, suitable for a cooler, though securing rails would be beneficial to prevent movement underway. Entertainment is supported by a Jensen AM-FM stereo system featuring MP3 connectivity, Bluetooth, and four directional speakers, allowing guests to enjoy music both onboard and while swimming off the stern. The helm itself is a single fiberglass module finished in an off-color to reduce glare, with a faux burl wood gauge panel housing three chrome-bezeled gauges. The hydraulic steering wheel is tilt-adjustable, and the engine control is mounted vertically. The captain's seat includes flip-up armrests and a pedestal base that allows swiveling to join conversations in the adjacent L-shaped seating. Further forward, two large couches face each other port and starboard, upholstered in UV-resistant vinyl with soft, multi-density foam cushions. A standard pedestal table can be positioned between these couches, creating an intimate social space. Storage compartments are located beneath all seating. The deck is covered with sculptured marine-grade carpet, with an optional vinyl cockpit flooring available. A color-matched 9-foot polyester BEMEDE top with LED courtesy lighting provides full sun protection.
Power and Performance
The Party Barge 22XP3 measures 22 feet 2 inches in length overall with a beam of 8 feet 6 inches. It has an empty weight of 2,840 pounds. During testing, with 20 gallons of fuel, two people aboard, and test equipment, the total weight was approximately 3,835 pounds. Powered by a 150-horsepower Mercury four-stroke engine driving a 15x15 inertia propeller, the boat achieved a top speed of 38.7 miles per hour at 5,600 rpm. At this speed, fuel consumption was 14.2 gallons per hour, yielding a range of 86 miles. The most efficient cruise speed was found at 3,000 rpm, producing 17.3 miles per hour while burning 3.85 gallons per hour. This allowed for an extended range of 141 miles with a 10% fuel reserve, equating to over eight hours of cruising. The boat planes quickly, reaching planing speed in 2.6 seconds, 20 mph in 4.7 seconds, and exceeding 30 mph in 8.6 seconds. Optimal fuel economy and ride comfort are achieved by trimming the bow up to a higher cruising attitude, which also contributes to a dry ride over waves. Handling characteristics include a stable, flat attitude during slow turns and a slight lean into performance turns. The helm response is precise, with a small turning radius consistent across speeds, and power adjustments near docks do not cause stern swing. When power is reduced, the boat settles back into a level position.
Conclusion
The SunTracker Party Barge 22XP3 successfully combines accessibility, comfort, and performance in a pontoon boat designed for social boating. Its multiple access points, spacious seating arrangements, and convenient features such as the pop-up changing room and ample storage enhance onboard enjoyment. The powertrain delivers strong acceleration, efficient cruising, and responsive handling, while the design maximizes usable space for up to ten passengers. Overall, this model presents a well-executed platform for entertaining and leisurely outings on the water.
