2020 Robalo R160 Boat in Madison, WI US
Built in 2020
R160
1 Engine (YAMAHA)
16 feet
Gas
Fiberglass/Reinforced
The only thing better than the smile after catching your first fish is the roominess of the R160. Sixteen feet never looked or felt so good. Upfront, a sizable casting platform is detailed with Diamond Lustre non-skid for sure footing while fishing. A sizable insulated locker is perfect for stowing fish or icing cold drinks.
Trades considered.
Price History
| Date | Event | Price |
|---|---|---|
| 9/4/25 | Initial price | $28,500 |
2020 Robalo R160 Video Tours
Boattest.com Review
Overview
The 2016 Robalo R160 is a 16-foot center console boat designed primarily for first-time boat buyers and anglers seeking a compact yet capable fishing vessel. Priced under $20,000, it includes a reliable engine, trailer, and Robalo's notable 10-year warranty. Despite its modest size, the R160 incorporates the same Kevlar-reinforced hull construction, stainless steel hardware, and meticulous craftsmanship found in Robalo's larger models, ensuring durability and quality.
Exterior Design and Deck Layout
The R160 features diamond lustre non-skid surfaces throughout, including the bow area, which is designed to withstand heavy foot traffic from fishermen and water sports enthusiasts. Stainless steel grab handles are strategically placed for safety. To maximize usable space at the bow, navigation lights have been relocated to the sides of the center console, and a pop-up cleat bearing the Robalo logo is installed forward, creating a clean and functional casting deck. The bow houses an insulated storage compartment with an overboard drain, suitable for storing drinks or keeping the catch fresh. Forward of the console, there is a second cooler with an optional cushion and six vertical rod holders. An optional 16-gallon livewell system further enhances the boat’s fishing capabilities. The forward-facing backrest on the center console conceals a large storage compartment for dry storage and the aft navigation light.
Cockpit and Additional Features
The cockpit offers a depth of 22 inches and 8-inch wide side cap rails for added security. The aft jump seats feature folding backrests that quickly convert the area into an extended casting platform. A fiberglass transom entry step is located on the starboard side for convenient boarding. Under the starboard jump seat, the battery switch and marine battery are housed, while the port side provides storage for a 5-gallon bucket. The gas tank is protected by a non-skid cover, and the engine mount includes a Robalo-branded backing plate. The helm seat is equipped with a reversible backrest and conceals a large integrated cooler with a 70-quart capacity, designed to also accommodate two additional 5-gallon buckets. The helm console includes an acrylic windshield framed in aluminum for strength and refined fit and finish. The console top features two indented, self-draining non-skid areas ideal for cell phones, and ample space is available below for optional electronics installation. The tilting steering wheel allows comfortable operation whether seated or standing, and the helm station provides generous legroom. A user-friendly kill switch attachment enhances operator safety.
Power and Performance
The Robalo R160 comes standard with a 60-horsepower Yamaha engine, with optional upgrades to 70 or 90 horsepower. The test boat was equipped with the 70-horsepower four-stroke Yamaha outboard. The vessel has a beam of 7 feet and a weight of 1,674 pounds. Thanks to Robalo's Hydra-Lift multi-angle hull design and extended V-plane running surface, the boat achieved plane in 6 seconds, reached 20 miles per hour in 8.7 seconds, and 30 miles per hour in 15.2 seconds. The top speed recorded was 35.1 miles per hour at 6,100 RPM, consuming 6.2 gallons per hour, which translates to a range of 62 statute miles on the standard 12-gallon fuel tank. An 18-gallon fuel tank option is also available for extended range. The optimal cruising speed was 25 miles per hour at 4,500 RPM, providing an 83-mile range. The boat’s shallow 10-inch draft facilitates access to shallow fishing areas.
Conclusion
The Robalo R160 offers a compelling value proposition as an entry-level new boat, combining quality construction, practical fishing features, and respectable performance at an accessible price point. While designed with anglers in mind, its versatility allows it to serve effectively as a light water sports boat suitable for family use. Overall, the R160 stands out as a durable, well-equipped, and affordable option for those entering the boating world.
Overview from around the web 2020 Robalo R160
Customers praise the 2020 Robalo R160 for its versatile design, making it ideal for both fishing and family outings
Many highlight its spacious deck layout, which provides ample room for gear and passengers, contributing to a comfortable experience on the water. The boat’s solid construction and smooth handling receive frequent commendations, with users appreciating its stability even in choppier conditions. Additionally, the R160’s fuel efficiency and reliable performance are noted as key advantages. Overall, owners value the combination of practicality, durability, and ease of use that the 2020 Robalo R160 delivers.
The Biggest Pros and Cons
The 2020 Robalo R160 is a versatile and well-designed bay boat that offers a range of benefits along with a few considerations to keep in mind. Here are the pros and cons:
Pros
Versatile Design: The R160 is well-suited for both inshore fishing and family outings, making it a great all-around boat.
Spacious Layout: Despite its compact size, the boat offers ample deck space for fishing, casting, and socializing.
Quality Construction: Robalo is known for solid build quality, and the R160 features durable materials and a sturdy hull design.
Fuel Efficiency: The boat’s size and hull design contribute to good fuel economy, ideal for longer days on the water.
Comfort Features: Equipped with comfortable seating, ample storage compartments, and a user-friendly helm, the R160 ensures a pleasant boating experience.
Shallow Draft: Its shallow draft allows for easy navigation in shallow waters, perfect for bay and coastal fishing.
Cons
Limited Seating Capacity: While adequate for small groups, the seating may be a bit tight for larger families or groups.
Basic Electronics Package: Some anglers may find the standard electronics setup minimal and might want to upgrade for enhanced navigation and fish-finding capabilities.
No Cabin or Enclosed Shelter: The open layout means less protection from the elements, which could be a drawback in inclement weather.
Storage Space: While sufficient for typical gear, storage might be limited for extended trips requiring more equipment.
Made For
The 2020 Robalo R160 is perfect for anglers and families seeking a versatile, reliable, and easy-to-handle boat. Its compact size and user-friendly design make it ideal for those who enjoy fishing inshore waters, cruising along coastal areas, or spending quality time on the water with loved ones. Whether you're a beginner or an experienced boater, the R160 offers a great balance of performance, comfort, and practicality for a variety of recreational activities.
Be the first to know when similar boats hit the market
Get notified when new boats become available
Boats For Sale in Wisconsin, United States Similar to the 2020 Robalo R160
Compare with similar boats and find the perfect one for you.
 2020 Robalo R160 | |||||
|---|---|---|---|---|---|
| $28,500 | $28,240 | $27,554 | $26,964 | $30,219 | $23,799 |
| Madison | Allenton | Appleton | Williams Bay | Sun Prairie | Green Bay |
| 16' | 16' | 16' | 13' | 16' | 16' |
| YAMAHA | MERCURY MARINE | MERCURY MARINE | Mercury | MERCURY MARINE | MERCURY MARINE |
| 70 hp | 75 hp | 60 hp | 40 hp | 75 hp | 60 hp |
| 278 | 710 | 242 | 31 | 43 | 347 |
