2024 Ranger Z520R
$92,600
Boat in Lexington, NC 27295 US
Built in 2024
Z520R
1 Engine (MERCURY MARINE)
20.9 feet
Gas
Fiberglass/Reinforced
With an unmatched legacy and never-ending drive for domination, we've created the next iteration of the go-to for anglers at every level. The Ranger Z520R is the next chapter in bass boat evolution and a quantum leap in design, functionality and dominating performance at every level. From the outset, we took the legendary Z Comanche "C" hull, digitally scanned and perfected it, resulting in an instant hole shot and stronger top-end. Every appreciable element of the cockpit, decks, and storages has been revamped to complement the enhanced performance of the R Series. We've also gone to great lengths to incorporate more standard technology into the R Series to not only raise the bar for the industry, but to give you greater convenience and peace of mind. An all-new console carries dual graphs or a single 16" unit and the touchscreen Ranger RIDE system that gives you control over every boat and engine function. The all-new seats rest on slides and CloudNine™ air ride shock system that takes the teeth out of chop. A key fob and new push-button ignition let you start up quicker and deliver greater security when you're on the road. Inside the coin box is a wireless phone charger, and in the battery box are standard lithium batteries. Storage boxes are demonstrably larger, thanks to redesigned stringer system that builds on our One-Piece Feel Interloc™ Construction. The rod boxes feature a tri-level storage shelf system that simplifies rod management and offers more room for sticks up to 9'. Inside and out, the Z520R lets you release a new level of domination. The Z520R. It's a whole new era of Ranger.
-
Length:20' 11"
-
Beam: 96"
-
Max. Recommended HP: 250 HP
-
Engine Shaft Length: 20"
-
Inside Depth: 22"
-
Fuel Capacity: 54 gal.
-
Livewell Capacity: 31 gal.
-
Total Person, Motor, Gear: 1650 lbs.
-
Approximate Boat Weight: 1850 lbs.
-
Rod Box Length - Port: 8' 0"
-
Rod Box Length - Center Row 1: 8' 0"
-
Rod Box Length - Center Row 2: 7' 6"
-
Max. Person Capacity: 4 persons
-
Trailer GVWR: 5400 lbs.
-
Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate): 27' 1"
-
Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate): 25' 0"
-
Width On Trailer: 102"
Custom Details
-
3 Level rod shelves port rod locker
-
2 Level rod shelves STBD rod locker
-
Power Ventilation Rod Storage™
-
Integrated rod and tackle management system
-
Double wall insulated cooler (10 gal) w/ drain
-
Stainless steel seat bases
-
Line spooling station under aft lid
-
Gas spring lid assists
-
Molded-in driver/ passenger footrests
-
Ranger® tournament measuring board
-
Remote drain plug
-
Stainless steel compression lid locks
Electronics
-
Lowrance® ELITE-9FS at bow
-
Lowrance® ELITE-9FS w/ Active Imaging at console
-
On-board Dual Pro™ charger, 15 x 3, auto detect lithium capable
-
Push to Start Ignition system with proximity keyfob
-
New Digital switching at bow with foot activated trim buttons
-
Console panel w/ Ranger® RIDE System (Ranger Intelligent Display Engine), integrating full-boat control and monitoring via 9" touchscreen
-
Heavy duty 6-gauge trolling motor wiring w/ 60 amp breaker
-
12V DC power receptacle with USB
-
LED compartment & livewell light package
-
Automatic box light sensors
-
Integrated LED bow navigation lights
-
Removable LED stern light
-
LED courtesy light(s)
-
Heavy duty 6-gauge electronics (MFD) wiring w/ 30 amp breaker
-
Solid state resettable switching w/ 30A master breaker
-
Wireless phone charger in coin box
Power/Performance
-
AGM starting battery w/ tray
-
Minn Kota® Fortrex 80 45" DSC 24V trolling motor
-
High performance stainless steel prop
-
Flush-mounted remote throttle control
-
(2) WRM80 lithium trolling motor batteries
-
Foam-filled unitized 1 pc fiberglass stringer system
-
Ranger I Beam Pultruded Fiberglass transom
-
Manual 10" setback plate
-
High performance steering wheel
-
Recirculating aerated livewell w/ removable divider
-
Dual livewell lids with cull bouy organizer STBD side
-
Venturi Air & livewell pump-out system
-
Integrated engine setback
-
Electrical system disconnect on/off switch
-
NOCO™ GB40 jump starter
-
Tilt hydraulic steering
-
Power trim
-
Recessed trolling motor foot pedal
Safety/Comfort
-
Upright, level flotation
-
Fire extinguisher & horn
-
Tinted windshield(s)
-
Pop-up tie cleats (drivers side cleat for easy tie up STD)
-
Integrated grab handles
-
Skid resistant material on bow
-
Automatic and manual bilge pump
-
Custom-fitted premium marine upholstery - Soft Ride Seating (SRS) bucket seats w/ center storage, (1) bike seat w/ pro pole, (1) SRS all-weather fold down w/ power pedestal
-
NASCAR-inspired molded fiberglass (CCBM) seat back color matched to boat
-
Stainless steel seat bases
-
NEW integrated boarding ladder
-
Padded front deck
Trailer Features
-
Tandem axle trailer
-
Aluminum wheels w/ matching spare tire & wheel
-
Matching fiberglass fenders w/ step pads
-
Hydraulic surge disc brakes
-
Swing-away tongue
-
Center swing jack (black powder coated)
-
NMMA®/NATM certified
-
Ranger Trail® Vault® Hub lubrication system
-
Ranger® Boats Road Armor Equipped® trailer protectant
-
Torsion axles
-
LED lighting
-
Stainless steel ratchet tie downs
-
(2) Back-up lights
Price History
| Date | Event | Price |
|---|---|---|
| 6/28/25 | Initial price | $92,600 |
2024 Ranger Z520R Video Tours
Overview from around the web 2024 Ranger Z520R
Customers are praising the 2024 Ranger Z520R for its exceptional performance and versatility on the water
Many highlight its spacious and comfortable layout, making it ideal for both fishing and family outings. The boat’s durability and advanced features, such as the upgraded electronics and powerful engine options, receive frequent commendations. Users also appreciate the smooth handling and stability, which enhance confidence during various water conditions. Overall, the 2024 Ranger Z520R is celebrated for delivering a premium boating experience that meets the needs of avid anglers and recreational boaters alike.
The Biggest Pros and Cons
The 2024 Ranger Z520R offers a range of features tailored for serious anglers and boating enthusiasts. Here are some pros and cons to consider:
Pros
Spacious and Functional Layout: The Z520R provides ample deck space and smart storage solutions, making it ideal for fishing and gear organization.
Powerful Performance: Equipped with a robust engine, it delivers excellent speed and maneuverability on various water conditions.
Advanced Electronics Integration: Comes pre-wired for multiple fish finders and other electronic devices, enhancing your fishing experience.
Durable Construction: Built with high-quality materials and a solid hull design, ensuring longevity and stability.
Comfort Features: Includes ergonomic seating and adjustable controls for a comfortable ride during long outings.
Cons
Price Point: As a premium bass boat, the Z520R may be on the higher end of the price spectrum, which could be a consideration for budget-conscious buyers.
Learning Curve: Some of the advanced features and controls might require time to master for beginners.
Limited Seating Capacity: Designed primarily for fishing, it may not accommodate large groups comfortably compared to recreational boats.
Made For
The 2024 Ranger Z520R is designed for serious anglers who demand top-tier performance and versatility on the water. Ideal for those who prioritize speed, stability, and cutting-edge technology, this boat is perfect for tournament fishermen and avid bass anglers looking to elevate their fishing experience. Whether you're navigating tight spots or cruising open waters, the Z520R offers unmatched control and comfort to help you fish smarter and more efficiently.
