2022 Ranger Z520R Boat in Harriman, TN 37748 US

• Length:20' 11"

• Beam: 96"

• Max. Recommended HP: 250 HP

• Engine Shaft Length: 20"

• Inside Depth: 22"

• Fuel Capacity: 54 gal.

• Livewell Capacity: 31 gal.

• Total Person, Motor, Gear: 1650 lbs.

• Approximate Boat Weight: 1850 lbs.

• Rod Box Length - Port: 8' 0"

• Rod Box Length - Center Row 1: 8' 0"

• Rod Box Length - Center Row 2: 7' 6"

• Max. Person Capacity: 5 persons

• Trailer GVWR: 5400 lbs.

• Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate): 27' 1"

• Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate): 25' 0"

• Width On Trailer: 102"

Custom Details

• 3 Level rod shelves port rod locker

• 2 Level rod shelves STBD rod locker

• Power Ventilation Rod Storage™

• Integrated rod and tackle management system

• Double wall insulated cooler (10 gal) w/ drain

• Stainless steel seat bases

• Line spooling station under aft lid

• Gas spring lid assists

• Molded-in driver/ passenger footrests

• Trim package featuring chrome and polished aluminum accents

• Ranger® tournament measuring board

• Remote drain plug

• Stainless steel compression lid locks

Safety/Comfort

• Upright, level flotation

• Fire extinguisher & horn

• Tinted windshield(s)

• Pop-up tie cleats (drivers side cleat for easy tie up STD)

• Integrated grab handles

• Skid resistant material on bow

• Automatic and manual bilge pump

• Custom-fitted premium marine upholstery - Soft Ride Seating (SRS) bucket seats w/ center storage, (1) bike seat w/ pro pole, (1) SRS all-weather fold down w/ power pedestal

• NASCAR Molded Fiberglass (CCBM) Seat to color match boat

• Stainless steel seat bases

• Integrated boarding ladder

• Padded front deck

Trailer Features

• Tandem axle trailer

• Aluminum wheels w/ matching spare tire & wheel

• Matching fiberglass fenders w/ step pads

• Hydraulic surge disc brakes

• Swing-away tongue

• Center swing jack (black powder coated)

• NMMA®/NATM certified

• Ranger Trail® Vault® Hub lubrication system

• Ranger® Boats Road Armor Equipped® trailer protectant

• Torsion axles

• LED lighting

• Stainless steel ratchet tie downs

• (2) Back-up lights

Power/Performance

• AGM starting battery w/ tray

• Minn Kota® Fortrex 80 24V trolling motor

• High performance stainless steel prop

• Flush-mounted remote throttle control

• (2) RB80 lithium trolling motor batteries

• Foam-filled unitized 1 pc fiberglass stringer system

• Ranger I Beam Pultruded Fiberglass transom

• Manual 10" setback plate

• New high performance steering wheel

• Recirculating aerated livewell w/ removable divider

• Dual livewell lids with cull buoy organizer STBD side

• Venturi Air & livewell pump-out system

• Integrated engine setback

• Electrical system disconnect on/off switch

• NOCO™ GB40 jump starter

• Tilt hydraulic steering

• Power trim

• Recessed trolling motor foot pedal

Electronics

• Lowrance® HDS-9 LIVE w/ AI at console

• Lowrance® HDS-7 LIVE at bow

• On-board Dual Pro™ charger, 15 x 3, auto detect lithium capable

• Push to Start Ignition system with proximity keyfob

• New Digital switching at bow with foot activated trim buttons

• Console panel w/ Ranger® RIDE System (Ranger Intelligent Display Engine), integrating full-boat control and monitoring via 9" touchscreen

• Heavy duty 6-gauge trolling motor wiring w/ 60 amp breaker

• 12V DC power receptacle with USB

• LED compartment & livewell light package

• Automatic box light sensors

• Integrated LED bow navigation lights

• Removable LED stern light

• LED courtesy light(s)

• Heavy duty 6-gauge electronics (MFD) wiring w/ 30 amp breaker

• Solid state resettable switching w/ 30A master breaker

• Wireless phone charger in coin box
