2025 Ranger Z520

Additional Specs

• Length:20' 11"

• Beam: 96"

• Max. Recommended HP: 250 HP

• Engine Shaft Length: 20"

• Inside Depth: 22"

• Fuel Capacity: 54 gal.

• Livewell Capacity: 31 gal.

• Total Person, Motor, Gear: 1650 lbs.

• Approximate Boat Weight: 1850 lbs.

• Rod Box Length - Port: 8' 0"

• Rod Box Length - Center Row 1: 8' 0"

• Rod Box Length - Center Row 2: 7' 6"

• Max. Person Capacity: 4 persons

• Trailer GVWR: 5400 lbs.

• Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate): 27' 1"

• Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate): 25' 0"

• Width On Trailer: 102"

Custom Details

• Ranger Echelon™ Rod Storage System - 3-tiered port & 2-tiered starboard rod lockers

• Power Ventilation Rod Storage™

• Insulated 40 qt. step-up cooler

• Integrated center-storage rod & tackle management system

• Stainless steel push-to-close locking latches

• Carpeted cockpit floor and compartment liner mats

• Ranger® tournament measuring board integrated at front deck step

• Runnin' rod rack w/ retractable strap

• Remote drain plug

• Tool holders at bow and front deck step

• Molded-in driver / passenger footrests

• Integrated stainless steel cup holders

Electronics

• Built to be Yours™ - Available with a wide array of custom-matched trolling motors, electronics, and accessories

• Mercury SmartCraft MercMonitor gauge package

• Push-Button solid-state digital switching

• Keyed ignition

• Solid-state digital keypad at bow with push-button trim switches

• Ranger® Umbilical™ dedicated bow-to-stern 6-gauge electronics wiring harness w/ 30A breaker

• Heavy Duty 6-gauge trolling motor wiring harness w/ 60A breaker

• Master Power on/off battery disconnect switch

• NOCO™ GB40 jump starter w/ on-board USB charging

• LED storage compartment lighting & LED courtesy & livewell lighting

• Integrated LED bow navigation lights & removable LED anchor light

• Lowrance® Elite FS™ 9 w/ Active Imaging™ HD at console

Power/Performance

• MinnKota® Fortrex 80lb , 45" DSC 24V trolling motor

• AGM Starting battery w/ tray

• One-Piece-Feel Interloc Construction

• Pultruded Fiberglass Transom

• Integrated engine setback

• 10" manual setback plate

• Hydraulic steering

• Recirculating aerated livewell w/ removable divider

• Venturi aeration system

• Recessed trolling motor foot pedal

• High performance stainless steel prop

• Foam-filled fiberglass stringer system

Safety/Comfort

• Upright Level Flotation exceeding all USCG & NMMA standards

• Custom-fitted premium marine upholstery - Soft Ride Seating (SRS) bucket seats w/ color-matched fiberglass seat shell, coin box, (1) bike seat w/ pro pole, & (1) SRS all-weather fold down w/ power pedestal

• Padded front deck

• Fire extinguisher & horn

• Stainless steel seat bases

• Pop-up tie cleats

• Integrated grab handles

• Rite Track Keel®

• Automatic & manual bilge pumps

• Integrated re-boarding ladder

Trailer Features

• Ranger® Boats Road Armor Equipped® trailer protectant coating

• Ranger Trail® Vault® Hub lubrication system

• Fiberglass fenders w/ step pads

• Hydraulic surge disc brakes

• Swing-away tongue

• Integrated center-swing jack finished in black powdercoat

• Stainless steel ratcheting tie-downs

• LED lighting

• LED back-up lights

• NMMA®/NATM certified
