2020 Nitro Z20 Boat in Raymond, IL 62560 US
Built in 2020
Z20
1 Engine (Mercury)
20.2 feet
Gas
Fiberglass/Reinforced
2020 NITRO Z20
250 MERCURY PRO XS EFI 4 STROKE WITH STAINLESS PROP
TANDEM AXEL TRAILER WITH STAIRSTEP, SWING TONGUE, BRAKE, SPARE
112 ULTREX TROLLING MOTOR I PILOT LINK 36V
BATTERIES
MINN KOTA PRECISION 4 BANK CHARGER
2-10' MINN KOTA TALONS
HUMMINBIRD HELIX 10 SI ON CONSOLE
BOW HUMMINBIRD HELIX 9DI & GARMIN ECHOMAP ULTRA 105SV WITH LIVESCOPE
ROD STRAPS
1 FOLD DOWN FISHING SEAT
1 BIKE SEAT
COIN BOX
HOT FOOT
TILT STEERING
SEA STAR PRO STEERING
LOADED!
Many professional tournament anglers choose the NITRO® Z20 because it competes favorably with 21-foot boats while being more compact for probing docks and shallower water. The basis of the Z20 is the NITRO VORTEX TECHNOLOGY™ (NVT™) hull-a design that uses a series of parabolic curves for quicker holeshots, more lift while on plane and improved handling.
The Z20 is optimized for tournament angling, with massive rod capacity in the two 8' bow rod lockers and an enormous center tackle storage compartment with NITRO-exclusive Tackle Management System™. It comes fully rigged on a custom-matched, tandem-axle trailer with GALVASHIELD® Impact protection.
- Length: 20' 2"
- Beam: 7' 10"
- Bottom width: 6' 3"
- Max. recommended HP: 250 HP
- Fuel capacity: 50 gal.
- Max. person capacity: 4 persons
- Max. person weight: 575 lbs.
- Max. person, motor & gear weight: 1750 lbs.
- Interior depth: 18"
- Transom height: 22"
- Deadrise: 16 degrees
- Draft: 16"
- Average dry weight: 2000 lbs.
- Average package weight: 4050 lbs.
- Package height: 6' 1"
- Package width: 8' 6"
- Towing length: 27' 0"
- Storage length: 23' 8"
Comfort, Convenience & Peace of Mind
- NMMA® certified
- Flotation meets or exceeds NMMA® & U.S. Coast Guard requirements
- EPA-compliant fuel system
- Anti-fatigue, padded comfort bow deck
- Non-skid mats bow & stern
- 5 drink holders
- 4 stainless steel pull-up cleats
- Integrated fold-down stainless steel reboarding ladder, angled for allowing optional shallow-water anchor
- 4 grab handles (1 at each seat)
- Built-in tournament ruler & holder
- Fire extinguisher
- Horn
- Paddle
Livewell Systems
- 2 aft 19-gal. (71.92 L) insulated Guardian™ livewells w/digital timers
- 750 GPH (2,839.06 LPH) livewell recirculation/pump-out system
- 500 GPH (1,892.71 LPH) aerator/fill pump
- Dual remote drain controls
- Rotomolded w/rounded corners
Trolling Motor
- Minn Kota® Maxxum® 24V, 70-lb. (31.75 kg) thrust, 42" (1.07 m) shaft, foot-control trolling motor
- Trolling motor pedal recess
Console
- NEW modular, aerodynamic console design w/expanded leg clearance & larger fishfinder surface
- Lowrance® HOOK2 5 Combo flush-mounted fishfinder
- Hydraulic steering w/tilt
- Removable acrylic, tinted windscreen
- Ready to accept optional removable port console
- Veethree® multifunction instrumentation w/speedometer/fuel gauge, tach/trim gauge, voltmeter gauge & water pressure gauge
- Dash light dimmer
- Waterproof, capacitive touch digital keypad
- LED courtesy light
- 12V outlet
Interior
- 42.5-sq.-ft. (4.0-sq.-m) anti-fatigue, padded bow deck for comfort & mobility
- Bike seat w/pedestal
- Folding fishing seat w/composite frame
- Z-Core™ seating system w/Force Flex suspension & contoured, rotomolded frame for driver & passenger seats
- NEW 1" (2.54 cm) lower, driver & passenger flat seat mounting
- Bow port & starboard rod hold-down straps
- Molded-in drainage channels around bow storage compartments
- Oversized, lockable bow port & starboard rod lockers w/lift assists for rods up to 8' (2.44 m)
- Rod organizer in port rod locker
- Oversized lockable bow center storage locker w/Tackle Management System
- Step to bow deck w/62-qt. (58.67 L) insulated cooler & removable trash receptacle
- Partner rod ramp w/rod handle organizer & hold-down strap
- Footrest w/non-skid mat under console(s)
- Step to aft deck w/lockable storage & removable tub
- Designated net storage behind seating
- 2 lift-out, molded aft storage boxes that will each accept seven 3700 tackle trays
- Molded utility rigging compartment for easy access to batteries & pumps & easy cleanup
- Lift-out tool/rope storage tray in rigging compartment
- Insulated aluminum lids w/welded corners
- 16-oz. (.45 kg) plush, marine-grade cut pile carpet on decks & floor
- Lockable latches
Performance
- NITRO® Vortex Technology™ (NVT™) hull for a smoother, drier ride
- Rapid Planing System™ (RPS™) for quicker holeshots & maximized speed
- 12" (30.48 cm) adjustable jack plate
- Rigging tube for organized wiring & abrasion resistance
- Stainless steel propeller
Construction & Exterior
- 100% composite deck core w/superior thermal stability & strength-to-weight ratio
- Deck & hull chemically bonded & mechanically fastened w/stainless steel fasteners every 2" (5.08 cm)
- Gelcoated stringer/liner system
- Foam-filled hull for optimal buoyancy & safety
- Full-width fiberglass-encapsulated composite transom
- Low-profile gunnels to maximize deck size & for easier casting
Electrical
- Angled bow panel w/trolling motor receptacle, anchor/light switch, trim switch & capability to flush mount most 12" (30.5 cm) fishfinders
- LED console courtesy light
- Manual LED-lighted bow gear storage
- Automotive-style labeled fuse panel w/cover
- Interstate® cranking battery
- 2 heavy-duty Interstate® trolling batteries
- 2-bank, 8-amp battery charger w/exterior receptacle
- 6-gauge trolling motor wiring w/50-amp circuit breaker
- E-Start emergency jump start system
- Master power switch
- Waterproof Deutsch plugin gauge connectors
- Water/abrasion-resistant connectors
Trailer
- Custom-fit, tandem-axle NITRO® trailer powder-coated w/GALVASHIELD® Impact corrosion & chip protection for improved durability
- 7-pin connector
- 14" (35.56 cm) custom aluminum wheels w/radial tires
- NEW surge disc brakes on both axles
- No Touch Vortex hub lubrication system w/6-year, 100,000-mile (1,609.34 km) limited warranty
- Spare tire carrier w/matching spare
- All-welded rectangular GALVASHIELD® frame
- Space-saving swing-away tongue to reduce storage length
- Heavy-duty winch w/nylon strap & bow safety strap
- Integrated winch stand step w/safety handle for easier boarding/reboarding at bow while boat is on trailer
- Outboard motor support to reduce hull & transom stress while towing
- Carpeted bunks & fender boards to protect hull
- Submersible LED lights
- Safety cables
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
Price History
| Date | Event | Price |
|---|---|---|
| 10/21/26 | Initial price | $45,995 |
2020 Nitro Z20 Video Tours
Nitro Z20: BoatTEST Review
Overview
The Nitro Z20 is a tournament-level bass boat engineered to deliver rapid transit to fishing locations while providing amenities typically found on higher-end models. Designed with performance and angler functionality in mind, the Z20 offers a balance of speed, handling, and fishing features that appeal to serious bass anglers.
Power and Performance
The Z20 is available with either a standard Mercury 225 Pro XS four-stroke engine or an upgraded Mercury 250 Pro XS four-stroke, the latter fitted on our test boat with a manually adjustable 12-inch jack plate. Measuring 20 feet 2 inches in length with a 7 foot 10 inch beam and a hull draft of 16 inches, the boat's empty weight is approximately 2,000 pounds. During testing, with two passengers, 30 gallons of fuel, and equipment aboard, the estimated weight was 3,105 pounds. Powered by the 250-horsepower Mercury engine paired with a 14 by 24 inch stainless steel three-blade Fury propeller, the Z20 achieved a top speed of 76.6 miles per hour at 6,200 RPM. Its optimal cruising speed was 26.3 miles per hour at 3,000 RPM, delivering a fuel consumption of 5.3 gallons per hour and an effective range of 223 statute miles while maintaining a 10% fuel reserve from its 50-gallon capacity. Acceleration tests demonstrated rapid planing capabilities, reaching planing in 3.8 seconds, 20 mph in 5.3 seconds, and 30 mph in 7.7 seconds. The boat's mid-range acceleration is robust, providing a firm ride without water washing over the transom during deceleration. Handling characteristics reflect its bass boat design, with the hull climbing onto the pad quickly and maintaining precise line-holding in arcing turns, even over wakes and choppy water. The Nitro Vortex Technology (NVT) hull features six full-length parabolic strakes and a keel pad that enhances stability and smoothness at speed. Construction employs hand-laid fiberglass with reinforced layers in high-stress areas, a 100% composite chemically bonded transom, and a one-piece stringer grid molded integrally with some storage compartments for added space and strength.
Cockpit and Helm Features
The cockpit is equipped with twin Z-Core bucket seats featuring force flex suspension and contoured frames, designed in collaboration with professional angler Kevin Van Dam to provide comfort and support even at high speeds approaching 75 miles per hour. An optional second console is positioned forward of the port seat for anglers who prefer to fish alongside the driver at speed. This console includes a locking glove box with a 16 by 6 inch opening and convenient grab handles. The helm console is outfitted with V3 analog gauges, including a tachometer with integrated trim indicator, speedometer with fuel gauge, and instruments for water pressure and voltage. Standard electronics include a Lowrance Hook 2 5 fish finder, with options for additional devices. Controls are logically arranged with master power and ignition switches to the port of the tilt steering wheel, and a switch panel on the starboard side managing navigation and anchor lights, bilge pumps, and livewell functions. The stereo remote and conventional shift-throttle controls are located outboard on the starboard side. Hydraulic steering is standard, and optional upgrades include a foot throttle and turn signal-style trim switches to facilitate hands-on wheel control at high speeds.
Deck Layout and Fishing Amenities
Access to the forward casting deck is via steps located between the consoles, flanked by cup holders and tool racks. Beneath a hinged step lies a 62-quart cooler equipped with a removable wastebasket and sandwich tray. The bow casting deck spans 42.5 square feet and is covered with an anti-fatigue paddock mat. Bungee cords on each side secure rods during transit. Standard equipment includes a Minn Kota 24-volt trolling motor delivering 70 pounds of thrust with a 42-inch shaft. The bow panel accommodates optional fish finders up to 12 inches and houses switches for navigation lights and outboard trim. Additional features include tool racks, cup holders, and a trolling motor foot pedal. Storage is abundant with three lockable, gas-strut-assisted lockers: a port rod locker capable of holding ten rods up to eight feet long, a lighted center locker with removable dividers and integrated cup holders, and an open starboard locker with clips for paddles and a fire extinguisher. Four-inch pull-up cleats on each side facilitate docking and fender attachment.
Aft Deck and Livewell System
The aft fishing deck measures 82 inches wide by 46 inches fore to aft and includes a 22-inch wide step between the cockpit seats. Under a non-skid hatch is a shallow storage tray, with additional storage for nets above the seats and a removable catch ruler integrated into the deck. A boarding ladder folds neatly into the aft port corner, complemented by a padded grab handle. Four hatches in the aft deck provide access to twin 19-gallon Guardian livewells featuring digital timers, 750-gallon power pumps, a recirculating system, and rounded corners for fish safety. Removable tubs with slots for seven Plano 3700 tackle trays flank the livewells. Behind these, a large hatch grants access to the battery switch, charger, and mechanical components. The electrical system includes dual trolling batteries and a dedicated engine start battery. A hinged panel reveals bilge and livewell pumps, and a removable tray above the batteries offers additional storage.
Trailer and Final Assessment
The Nitro Z20 is delivered on a custom-made trailer featuring a swing-away tongue for ease of transport and storage. Overall, the Z20 presents as a tournament-quality bass boat that combines strong performance with thoughtfully integrated fishing amenities. The incorporation of the new Mercury four-stroke outboard maintains its competitive edge in speed and handling, making it a compelling choice for serious anglers seeking a balance of power, comfort, and functionality.
Overview from around the web 2020 Nitro Z20
Customers rave about the 2020 Nitro Z20, highlighting its exceptional performance and innovative features
Many users appreciate its spacious layout and ample storage, making it perfect for both recreational fishing and competitive tournaments. The boat's smooth ride and impressive speed are frequently praised, with anglers noting how it handles rough water with ease. The advanced electronics and fish-finding capabilities also receive high marks, ensuring that every fishing trip is more productive. Additionally, the Nitro Z20's sleek design and attention to detail have drawn compliments, emphasizing both aesthetics and functionality. Overall, the 2020 Nitro Z20 is celebrated as a robust, reliable choice that meets the diverse needs of passionate boaters and anglers alike.
The Biggest Pros and Cons
The 2020 Nitro Z20 is a highly regarded bass boat that boasts several features designed to enhance both performance and comfort on the water. Here are some pros and cons to consider:
Pros
Stability and Performance: The Z20 features a wide beam which provides excellent stability at high speeds and during rough water conditions, making it a reliable choice for both seasoned anglers and weekend warriors.
Spacious Design: With ample storage space, including dedicated compartments for rods, tackle, and other gear, the Nitro Z20 makes it easy to stay organized while on the water.
Powerful Engine Options: The boat comes with various engine configurations, allowing for impressive speed and acceleration, which is essential for reaching fishing spots quickly.
Advanced Technology: Equipped with cutting-edge electronics and sonar technology, the Z20 helps anglers locate and target fish more effectively.
Comfort and Amenities: The cockpit area is designed for comfort, with ergonomic seating and options for enhanced features such as a superior sound system and additional charging ports for devices.
Quality Build: Nitro is known for its durable construction, and the Z20 is no exception, featuring high-quality materials that ensure longevity and reliability.
Cons
Price Point: The Nitro Z20 is positioned as a premium model, which may be a significant investment for some buyers compared to budget-friendly alternatives.
Fuel Efficiency: While powerful, some users may find that the engine choices tend to consume fuel at a higher rate, particularly when operating at full throttle.
Weight: Due to its robust design and added features, the Z20 can be heavier than some competitors, which may affect towing and maneuverability for certain vehicles.
Learning Curve: For inexperienced boaters, the numerous features and technologies may have a learning curve that could initially overwhelm new users.
Customization Costs: While the boat offers various options, fully customizing the Z20 with upgraded electronics and accessories can significantly increase the overall cost.
Made For
The 2020 Nitro Z20 is designed for avid fishermen and boating enthusiasts seeking a high-performance, versatile fishing machine. Ideal for competitive anglers, the Z20 offers a perfect blend of speed, stability, and storage capacity, ensuring that you can tackle a variety of water conditions with confidence. The spacious layout makes it accommodating for both solo excursions and group outings, while advanced features like the powerful outboard engine and cutting-edge electronics make it suitable for serious tournament fishing. Whether you're chasing bass, walleye, or just enjoying a day on the lake, the Nitro Z20 provides the functionality and comfort needed for an exceptional experience. With ample storage for tackle, gear, and personal items, as well as innovative design elements that enhance accessibility and performance, this boat caters to those who demand the best in their fishing adventures.
