2016 MasterCraft NXT22 Boat in Mooresville, NC 28117 US
Built in 2016
NXT22
1 Engine (Ilmor)
22 feet
--
Fiberglass/Reinforced
2016 MasterCraft NXT22 - 22 feet of MasterCraft performance, style, and watersports capability.
This 2016 MasterCraft NXT22 combines proven MasterCraft construction with the performance and versatility needed for wakeboarding, wakesurfing, cruising, and family days on the water.
Powered by the Ilmor MV8 5.7L V8 with V-drive, this NXT22 delivers strong, smooth performance while the factory NXT Surf Package, ballast system, and NXT Tower make it a serious watersports platform.
The boat features a striking Midnite Black and White exterior complemented by a Garapa Gold swim platform and a Carbon/Platinum/Midnite Black interior.
Performance & Watersports- Ilmor MV8 5.7L V8
- V-drive transmission with 1.56:1 gear ratio
- 4-blade 14.75" propeller
- NXT Surf Package
- Triple-tank under-floor ballast system
- Zero Off GPS-based speed control
- NXT Tower
- Swivel board racks
- Removable rear ski pylon
- Two JL tower speaker cans
- MasterView VR100 mirror
With seating for up to 14 people, the NXT22 provides plenty of room for family and friends. The interior features premium-grade, UV-resistant vinyl designed to resist mildew and stains.
- MasterView Driver Bolster Seat
- Carbon/Platinum interior with Midnite Black accents
- Flat carpet flooring
- Garapa Gold swim platform
- 25-quart Igloo cooler
- Black Bimini cover
- Black boat cover
- 14 drink holders
- Interior courtesy lighting
- Three 12-volt power outlets
- Water-resistant glove box
- Molded-in transom boarding step
- Pull-up bow and stern cleats
- Anchor pull-up cleat
- Windshield-mounted mirror
The helm features MasterCraft's 4.3-inch color LCD display with a 5-button interface, providing important engine and boat information including speed, tachometer, engine temperature, fuel level, oil pressure, and air temperature.
- Factory stereo system
- Depth/temperature sensor
- Billet-accented dash
- Custom Gussi steering wheel
- Tilt helm
- Competition throttle with billet knob
- Zero Off GPS speed control
- 100% composite construction
- Composite integrated stringer system
- Stainless and non-corrosive hardware
- Automatic/manual bilge pump
- Bilge blower
- Automatic fire extinguisher system
- Engine warning alarms
- Low-voltage battery alarm
- Safety lanyard kill switch
- Horn
- Curved safety-glass windshield
- High-pressure in-tank fuel pump
- EPA-approved fuel system
- Year: 2016
- Make: MasterCraft
- Model: NXT22
- Length: 22' 0"
- Length with swim platform: 23' 10"
- Beam: 98"
- Dry weight: 4,200 lbs
- Fuel capacity: 50 gallons
- Draft: 28"
- Capacity: 14 people / 2,312 lbs
- Engine: Ilmor MV8 5.7L V8
- Drive: V-drive
- Hull: Midnite Black / White
- Interior: Carbon / Platinum / Midnite Black
- Swim platform: Garapa Gold
The 2016 MasterCraft NXT22 is built for memorable days on the water, whether you're cruising with family and friends or spending the day wakeboarding and wakesurfing. With its Ilmor 5.7L V8, NXT Surf Package, factory ballast, NXT Tower, premium interior, and extensive watersports equipment, this boat is ready for its next adventure.
Boat Serial Number: MBC3ZAK6F516
Equipment and specifications should be independently verified by the buyer. Condition, engine hours, service history, and other equipment should be confirmed with the seller.
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
Price History
| Date | Event | Price |
|---|---|---|
| 8/30/26 | Initial price | $59,900 |
MasterCraft NXT22: BoatTEST Review
Overview
The Mastercraft NXT 22 is a recently redesigned and upgraded towboat that caters to both active families and water sports enthusiasts. Positioned as one of Mastercraft's highest volume models, it offers a compelling balance of value and performance with a base 373 horsepower V8 Ilmor 6.0 liter engine. The 2023 model year introduces the all-new Gen 2 surf system, which automates ballast, trim tabs, and GPS speed settings to create customizable wake profiles at the touch of a button.
Gen 2 Surf System and Wake Customization
A major highlight of the NXT 22 is the Gen 2 surf system, designed to simplify wake shaping for various skill levels. This system eliminates manual adjustments by providing factory preset profiles accessible via the helm touchscreen. Operators can select from surf left or right, wake (with full ballast for intermediate to advanced riders), wake beginner (zero ballast with a target speed of 17.5 mph), and a ski profile (no ballast and higher speed). The system controls five ballast tanks—one front, two aft, and two Gen 2 bags atop the aft tanks—allowing on-the-fly wave adjustments. Manual overrides for ballast and trim are also available alongside the automated settings, while an attitude adjustment plate provides additional bow control.
Exterior Design and Deck Layout
The NXT 22 measures 23 feet 10 inches in length overall, with a beam of 8 feet 3 inches and a draft of 2 feet 4 inches. Its distinctive pickle-fork bow features a sporty, flared design that enhances both aesthetics and functionality by improving wake transition and reducing hull shock. The bow interior is spacious and comfortable, measuring 3 feet 5 inches long by 4 feet 10 inches wide, with wrap-around bolsters and hinged side seats that provide access to storage compartments. Additional storage includes an anchor locker beneath the center bow cushion and port-side compartments. The boat is equipped with five pull-up cleats strategically placed for convenience. An optional teak swim platform adds an upscale touch and integrates seamlessly with the boat’s painted topsides.
Helm and Cockpit Features
The helm is ergonomically designed with a tilt base and a rubberized steering wheel that ensures a secure grip even when wet. Engine gauges are mounted directly ahead on black anodized panels, with blower and bilge switches to port and light controls to starboard. The Gen 2 surf system touchscreen and ballast controls are conveniently located below the wheel. The throttle is positioned for easy, precise speed adjustments and is complemented by a fully adjustable helm chair with a flip-up bolster. A rear-facing spotter seat is located to port, adjacent to a dry storage compartment equipped with a courtesy light, 12-volt outlet, and slip-resistant matting. The cockpit features a classic towboat layout with wrap-around bench seating, an aft-facing companion seat, and ample storage beneath hinged seats. The battery bank, breakers, and main shut-off switch are housed beneath the port bench, while SeaDek-treated steps facilitate safe entry and exit at the stern. The collapsible tower with integrated bimini includes swiveling board racks and a fixed tow rope post, with Klipsch audio speakers mounted on the crossbar.
Power and Performance
Powered by the upgraded Ilmor 6.0 liter V8 engine producing 373 horsepower, the NXT 22 delivers strong performance and efficient fuel consumption. During testing, the boat reached a top speed of 40 miles per hour at 5,200 RPM. Economical cruising was achieved at 3,500 RPM, corresponding to 25 miles per hour. Endurance tests showed 4.8 hours at 3,000 RPM (18.5 mph) and 6.8 hours at 2,500 RPM (11.5 mph), indicating solid range for extended outings. Handling characteristics were agile and responsive, with smooth transitions through gradual and tight turns, no noticeable slippage, and excellent helm feedback. The 3.5 turns lock-to-lock steering and 12-inch rudder contribute to precise control. The pickle-fork bow design aids in cutting through wakes with minimal hull shock, maintaining a calm ride for passengers.
Conclusion
The Mastercraft NXT 22 presents a spacious, well-equipped, and versatile towboat that successfully blends entry-level pricing with upscale features. Its advanced Gen 2 surf system simplifies wake customization for riders of all skill levels, while the refined hull design and powerful engine deliver confident handling and performance. The ergonomic helm layout, ample storage, and comfortable seating make it suitable for families and water sports enthusiasts alike. With a range of available options, buyers can tailor the NXT 22 to their specific preferences, maintaining Mastercraft’s reputation for quality and innovation.
