2005 Lyman-Morse 38 Express Boat in Newport, RI 02840 US

UPDATES & UPGRADES

• Hull re-painted
• All new exterior varnish, 2026
• Upgraded Electronics with new Garmin large touch screen
• Engine removed and completely rebuilt
• Engine room painted
• Teak swim platform restored
• Replaced AL single actuator hydraulic trim tabs with SS electric dual actuators
• Replaced AL stabilizer fins with SS longer fins
• Replaced complete fuel flow management system
• Two new electronic fuel tank monitor sensors
• Jet serviced every year complete with sand blasting, prime, paint, impeller strip, new o-rings, zincs and lube
• New anchor sump box and pump
• All hatches with new glass and gaskets
• Replaced hydraulic hoses and fittings on steering system
• Rebuilt hydraulic lift at pilothouse

ENGINE WORK

• Clutch assembly, replaced 2025
• Hamilton Jet thrust bearing and seals
• Bow thruster motor

CONSTRUCTION, HULL & DECK

SCRIMP (Seemann Composites Resin Infusion Molding Process) infused E-Glass hull with vinylester resin surrounding a Corecell coring for hull rigidity and sound deadening qualities. The decks feature vacuum-bagged hand-laid E-Glass for tough and efficient use of the vinylester resins.

• Hull Color: Beaujolais Red with clear coating
• Modified-V with a hard-chine
• Custom Bow Rail
• Large teak swim platform (restored) with flush rollers for tender deployment
• Cockpit Settee, aft-facing with Storage below
• Windshield Wipers/Washers
• Perko rod holders
• Cockpit shower
• Saltwater washdown

ENGINE & MECHANICAL

• 7.4L Yanmar 6CX-6TE2 (fully rebuilt & repainted 2018) 500hp @ 2900rpm connected to a TWIN DISC M650075 1.1:1 with a HAMILTON 362 Jet Drive; 318 hours as of 03 Sept 2026 (since rebuild)
• Alternator, belt-driven
• Side-Power SP55 Bow Thruster
• Bennett Trim Tabs
• Maxwell 1500 Windlass
• MarineAir Vector Reverse Air Conditioning System, 12K
• Racor Duplex Fuel Filters
• Propane – (2) 10lb. Cylinders
• Toilet – Headhunter
• Refrigeration – Frigoboat

ELECTRICAL

• Northern Lights 5kW Genset (700 hrs Sept. 26)
• Meridian Marine AGM Batteries; Starting and House Bank, NEW April 2021
• Inverter 12/2000
• Mastervolt Charger 12V
• Shorepower 120V

MAIN DECK

• Drop-down Canvas/Isinglass
• L-shaped Lounge
• Overhead Vents
• Custom Headliner

HELM & ELECTRONICS

• Helm Station, starboard
• (2) STIDD Captain and Companion Helmseats in “Off White” with footrests, port & starboard
• Garmin GPSMAP 8617 Chart Plotter
• Garmin GRM Fathom 4' Open Array
• Garmin DST800 Transducer
• Garmin GMI20 Instrument Display
• ICOM VHF Marine IC-M602
• Ritchie Power Damp Compass
• Chart Table at Companion, port
• Companionway Pocket Entry Door, slides into bulkhead

LOWER DECK

• Ships electrical panel
• Dinette with Straight Settee , port
• Teak Table with inlay décor and extender leaf, port
• Bookcase with Fiddles, above Settee, port
• Portlights
• Head Compartment with Headhunter marine toilet, sink & faucet and shower, starboard

GALLEY

• Princess 3-burner LPG Stovetop
• Sharp Microwave
• Granite Countertop
• Sinks: Deep Double Chrome Sinks
• Frigobot Refrigerator / Freezer
• Numerous Storage Drawers & Compartments
• Grab Rail, Overhead
• Overhead Lighting

STATEROOM

• Custom bi-fold door entrance
• V-Berth with filler cushion
• Storage drawers below berth
• Hanging Lockers, cedar-lined

SAFETY EQUIPMENT

• 2 Fixed fire extinguishers
• 2 Rule 2700gph bilge pumps
• 35 CQR Plow anchor with 5/16 chain rode
• ACR remote searchlight
• EPIRB on cabin top
• Ships horn
• Smoke and carbon monoxide detectors
