2008 Lazzara Yachts LSX 75 Boat in Dania, FL 33004 US

Vessel Overview

• Year: 2008

• Make: Lazzara

• Model: 75 LSX Quad

• Builder: Lazzara Yachts Corp.

• Vessel Type: Motor Yacht

Dimensions & Construction

• Length Overall: 76' 9"

• Beam: 18' 2"

• Draft: 3' 6"

• Displacement: 78,000 lbs.

• Gross Tonnage: 88 GRT

• Net Tonnage: 70 NRT

• Hull Material: Fiberglass Reinforced Plastic (FRP)

• Hull Design: Modified-V

• Superstructure Material: Fiberglass Reinforced Plastic (FRP)

• Transom: Reinforced FRP

• Hull Color: White gelcoat with black boot stripes

Engines & Propulsion

• Engine Manufacturer: Volvo Penta

• Number of Engines: Four

• Engine Type: Diesel

• Horsepower: 435 HP per engine

• Total Horsepower: 1,740 HP

• Engine Hours: Approximately 485 hours per engine

• Drive System: Volvo Penta IPS pod drives

• Transmission Manufacturer: Volvo Penta

• Transmission/Drive Type: Pod drives

• Propellers: Duo-propellers on each pod

• Engine Controls: Electronic lever controls and joystick controls

• Engine Synchronizer: Electronic

• Cooling System: Freshwater reservoir cooling with raw-water-cooled wet exhaust

• Trim Tabs: Hydraulic

Performance

• Cruising Speed at 2,800 RPM: 19 knots

• Cruising Speed at 3,100 RPM: 24 knots

• Maximum Speed at 3,500 RPM: 28 knots

Fuel System

• Fuel Type: Diesel

• Fuel Tank Material: Aluminum

• Total Fuel Capacity: 830 gallons

• Fuel Tank Location: Centerline beneath the cabin sole

• Fuel Filtration: Racor filters and engine-mounted filters

• Fuel Fill Location: Starboard side

Generator & Electrical Systems

• Generator Manufacturer: Kohler

• Generator Model: 32E0ZD

• Generator Output: 32 kW

• Generator Fuel: Diesel

• Generator Voltage: 110/220V AC

• Generator Hours: Approximately 766 hours

• AC Electrical System: 120/240V AC

• DC Electrical System: 12V and 24V DC

• Shore Power: 250V, 100-amp inlet

• Shore Power Cord: 100-amp cord with Glendinning Cablemaster

• Battery Configuration: Eight Group 31 batteries and two 8-D batteries

• Battery Chargers: ProMariner 24-30P, Charles 60-amp 24V DC, and Charles 30-amp chargers

• Battery Charging: Alternators on each engine

• Galvanic Isolation: Charles Iso Boost transformer

Freshwater & Sanitation

• Freshwater Capacity: 200 gallons

• Freshwater Tank Quantity: One

• Hot Water System: 220V marine-grade system

• Hot Water Heater Capacity: Reported 28 gallons

• Watermaker: Sea Recovery

• Reported Watermaker Capacity: 600 gallons per day

• Holding Tank Capacity: 100 gallons

• Sanitation System: Electric heads

• Number of Heads: Six

• Waste System: U.S. Coast Guard Type III marine sanitation device

• Showers: Stand-up showers in the heads

Accommodations & Interior

• Guest Staterooms: Four

• Master Stateroom: Aft, centerline

• Forward Stateroom: Forward guest stateroom

• Additional Guest Staterooms: Port and starboard

• Crew Quarters: Separate aft crew quarters

• Heads: Five full heads plus a salon day head

• Salon: Main salon with large galley and dinette area

• Flooring: Carpet throughout the interior

• Interior Bulkheads: Composite bulkheads bonded to the hull with FRP

• Windows: Large fixed windows along the cabin sides

• Salon Access: Sliding salon door

• Interior Storage: Multiple storage areas

Galley & Domestic Systems

• Galley: Large galley integrated into the salon and dinette area

• Freshwater Pump: 220V AC demand pump

• Water Filtration: Inline filter at the freshwater pump

• Dockside Water: Pressure regulator installed

• Waste Disposal: Electric head system

Helm, Navigation & Electronics

• Helm Location: Elevated bridge deck

• Helm Seating: Single helm seat with adjacent bench seating

• Windshield: Three-sided windshield

• Navigation Electronics: Three display screens interfaced with Furuno software

• Engine Controls: Electronic lever controls

• Joystick Controls: Two cockpit joysticks

• Navigation Lights: Running lights

• Steering: Powered steering system

Exterior & Deck Equipment

• Decking: Teak on the foredeck, side decks, and cockpit

• Bow Rail: Stainless-steel stanchions and rail system

• Anchor Platform: Steel platform with bow roller

• Deck Hardware: Stainless-steel cleats and chocks

• Cockpit: Self-bailing cockpit

• Bridge Hardtop: Hardtop with powered retractable sunroof

• Swim Platform: Extended swim platform

• Tender Storage: Built-in transom garage

• Transom Access: Boarding system with access on both sides

• Grab Rails: Installed along cabin sides and in various locations

• Hatches: Circular foredeck hatch

• Bilge Pumps: Four Rule 2000 bilge pumps

• Engine Room Ventilation: Power blowers and hull vents

Additional Systems-

• Bilge Water Alarms: High-water alarms

• Engine Room Fire Suppression: Fixed fire-extinguishing system

• Fire Extinguishers: Six portable units

• Trim System: Hydraulic trim tabs

• Propulsion Water Intakes: Crash valves installed

• Exhaust System: Raw-water-cooled wet exhaust
