2024 Helmsman Trawlers 43E PILOTHOUSE
$875,000
Boat in Seattle, WA 98109 US
Built in 2024
43E PILOTHOUSE
1 Engine (Cummins)
43 feet
Diesel
Fiberglass/Reinforced
Features and Options
Two stateroom configuration
Cummins QSB6.7-380 engine (669 hours)
- dual-station controls
DMS MagnusMaster anti-roll stabilizer system
Northern Lights 6 KW generator (832 hours) in sound enclosure with exhaust water/gas separator (underwater discharge)
Victron 3000 VA inverter / charger
Victron isolation transformers (2) on shore power circuits
Two (2) Additional Northstar AGM house batteries
Flybridge hardtop wired for electronic antennas
Two pedestal seats at flybridge helm
L-shaped flybridge settee
Cocktail table
Four (4) courtesy lights in bridge
Canvas covers for flybridge chairs, seats and controls
Propane tanks (2) in flybridge settee
Solar panel system - five (5) 225 watt ridgid panels - 3 pilothouse roof and 2 on hardtop
Victron smart solar MPPT controller 100/50 - Victron MPPT control meter
Lewmar V4 anchor windlass with drum capstan and 250' of 5/16"HT chain
Bow rail extension over anchor roller
Fresh water connection for anchor washdown, additional to standard raw water connection
Side-power SE100 Bow Thruster- with handheld thruster remote control
Side-power SE80 Stern Thruster
Nick Jackson 750# LP davit - port side
Highfield Classic 310 console dinghy w/Scotty downrigger mount and Garmin depth sounder - Highfield flush dinghy mounts - dinghy storage cover
Novakool RFU9000 refrigerator/freezer - with teak veneer door panels - freezer on bottom
Force 10 propane galley stove w/ oven
Microwave in centerline cabinet
Pull-out storage drawers (2) - galley bookshelf - above pilothouse settee
Fold-up galley extension cutting board
Wine glass rack
LED undercabinet lighting in salon
White wood interior blinds
Sounddown acoustic absorption foam lining on hull interior in master stateroom
Caframo Scirocco II fans (3) one in master stateroom - one in guest stateroom - one in pilothouse
Single berth conversion in pilothouse
Bomar aluminum framed windows
Three separate Weems & Plath instruments above helm
Flip-up helm seat - lower helm
Reverso oil change system
Two (2) Webasto AT55 forced-air furnace systems
Three (3) reverse-cycle units
Blue Water Desalination 360 gpd watermaker
Torrid 17 gal. SS water heater
Splendide washer/dryer
Two (2) cockpit side entry doors
Two (2) pilothouse bulwarks side entry doors
Fold-down FRP table in cockpit
Grab rail mounted on the underside of the cockpit cover
Two (2) swim platform safety rails - staples
ROCA wiper/washer system
Pilothouse window covers
Boot, flybridge cowling and under gunwale accent stripes
Two (2) Marinco 2125 DC outlets in cockpit for Scotty downriggers
50' SmartPlug hybrid shore power cord
Electronics
Garmin GPSMAP 8617 Glass Bridge MFD ( lower helm)
Garmin GPSMAP 8616xsv MFD ( Upper helm )
Garmin Fantom 24 48NM Radar
Vesper Cortex V1 VHF Radio & AIS
2x GC14 marine cameras and FLIR thermal camera
Garmin GHC 50 autopilot (dual station) w/rudder feedback sensor & hydraulic pump
Fusion RA770 stereo system with Apollo amplifier, Fusion 6.6" speakers , Polk 4" speakers, 10" subwoofer
T V w/soundbar and wireless subwoofer
Stereo speakers in salon, pilothouse and flybridge
Subwoofer in salon for stereo
Standard Starlink dish
**LIVE Virtual Showing Available! This Helmsman Trawlers 43E has been photographed to enable a hosted LIVE virtual tour. Contact Helmsman Trawlers to schedule your LIVE Virtual Showing.**
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
Price History
| Date | Event | Price |
|---|---|---|
| 3/27/26 | Price decreased | $875,000(-1.1%) |
| 3/5/26 | Price decreased | $885,000(-1.1%) |
| 2/26/26 | Initial price | $895,000 |
2024 Helmsman Trawlers 43E PILOTHOUSE Video Tours
Boattest.com Review
Overview
The Helmsman Trawler 43 E is a coastal cruiser designed specifically for the owner-operator, emphasizing ease of handling and thoughtful design features. This vessel combines practical operational elements with customizable electronics and a focus on comfort and functionality, making it well-suited for coastal cruising and single-handed operation.
Exterior Design and Deck Layout
The vessel features a clean and uncluttered deck layout with wide open spaces and non-skid surfaces molded into the deck for safety and ease of maintenance. The bow is equipped with polished stainless steel 32-inch high rails and a 20-kilogram anchor mounted on a roller with a swivel, managed by a Lum Mar windlass with both foot and remote controls. A large, draining rode locker beneath the hatch provides ample storage for fenders and lines. The boat’s rails are robust with polished welds, and the cleats measure 10 inches, reflecting quality craftsmanship. A collapsible antenna arch on the flybridge allows for reduced bridge clearance, and the flybridge itself offers a spacious helm station on the starboard side with a weatherproof pedestal seat and a wide open boat deck area suitable for additional seating or equipment installation, such as a crane.
Pilot House and Helm Features
The pilot house is designed with forward-raked windows to minimize glare, each equipped with individual windshield wipers. The center windshield opens electrically and can be securely dogged to maintain watertight integrity. Side doors on both port and starboard provide excellent ventilation and convenient access for line handling, a critical feature for owner-operators. The helm station includes two carbon fiber panels—one high and one low—allowing for customizable electronics layouts, such as multifunction displays and thruster controls. The steering wheel is vertically mounted and complemented by a footrest, while the helm seat offers adjustable height, swivel, and a flip bolster for comfort. The overhead clearance is generous at six feet, seven inches, and ventilation is enhanced by an overhead hatch and side windows. Adjacent to the helm is an L-shaped settee on a raised platform with storage underneath and a thoughtfully integrated headrest, along with a high-low pedestal table. Additional workstation space behind the helm includes storage, generator controls, electrical panels, and battery switches.
Engine Room and Mechanical Systems
Accessed via a hatch in the raised pilot house, the engine room is well-organized and spacious, centered around a Cummins QSB 6.7-liter 380-horsepower engine. The layout provides easy access to all service points, including battery chargers, fuel filters with crossover, and suction gauges. House batteries are located aft of the engine, and a washer-dryer unit and six-kilowatt generator are accessible from a separate hatch in the salon. The engine room floorboards are removable without tools, allowing straightforward inspection and maintenance. Noise reduction is a key design element, with multiple layers of sound-dampening materials incorporated into the deck construction above the engine, contributing to a quiet pilot house environment. Additional mechanical features include twin 30-amp shore power connections with the ability to split loads, isolation transformers for marina compatibility, and a bow thruster with dedicated battery. A telltale water flow indicator near the exhaust allows the operator to verify engine cooling water discharge without leaving the helm.
Performance and Handling
The Helmsman Trawler 43 E measures 45 feet overall with a beam of 14 feet, 2 inches, and a draft of 4 feet, 6 inches. The test weight was approximately 36,355 pounds, including fuel and crew. Powered by a single 380-horsepower Cummins engine turning a 24 by 26-inch propeller, the boat achieved a top speed of 11.3 knots at 3000 RPM. Typical cruising speeds range from 7.3 to 8.2 knots, with fuel consumption between 2.7 and 4.3 gallons per hour, yielding a range of 857 to 1201 nautical miles depending on speed. Maneuvering in tight quarters is facilitated by powerful bow and stern thrusters and a sizable rudder, allowing the vessel to turn nearly on its own length. Docking is straightforward, aided by excellent visibility and intuitive controls. The boat naturally backs to starboard in reverse, a characteristic that can be leveraged for precise docking maneuvers. Overall, the handling characteristics make this trawler particularly well-suited for single-handed operation.
Conclusion
The Helmsman Trawler 43 E presents a well-rounded package for the owner-operator seeking a coastal cruiser with straightforward systems, thoughtful design, and excellent handling. Its customizable electronics layout, comfortable and ventilated pilot house, robust mechanical systems, and efficient performance underscore its suitability for extended cruising and easy single-handed operation. Additional features such as isolation transformers, dual shore power connections, and provisions for solar panels enhance its versatility across various cruising grounds. This vessel balances simplicity with functionality, making it an appealing choice for those prioritizing ease of use and reliability.
Overview from around the web 2024 Helmsman Trawlers 43E PILOTHOUSE
Customers are praising the 2024 Helmsman Trawlers 43E Pilothouse for its exceptional design, functionality, and comfort
Many appreciate the spacious and well-thought-out layout that maximizes living space while offering a practical and stylish environment for both cruising and entertaining. The pilothouse configuration is frequently highlighted for providing excellent visibility and protection from the elements, allowing for safe and enjoyable navigation regardless of weather conditions. In addition, owners have commended the high-quality craftsmanship and durable construction synonymous with Helmsman Trawlers. The efficient propulsion system and fuel economy are often mentioned, making it a practical choice for long-distance cruising. Customers also comment on the exceptional storage solutions and modern amenities that elevate their experience on the water, such as the well-equipped galley and comfortable staterooms. Overall, the 2024 Helmsman Trawlers 43E Pilothouse has garnered positive reviews for its blend of performance, comfort, and style, making it an ideal vessel for both experienced mariners and those new to boating.
Made For
The 2024 Helmsman Trawlers 43E PILOTHOUSE is designed for the discerning boater who prioritizes both comfort and functionality. Ideal for couples or small families, this trawler is perfect for those who crave adventure on the open water while also desiring the comforts of home. With its spacious layout and well-appointed features, it caters to seasoned mariners looking to extend their voyages, as well as newcomers eager to explore coastal waters. Whether you're planning a weekend getaway or a longer journey, the 43E PILOTHOUSE excels in providing a safe and stable platform for cruising. Its robust construction and efficient design appeals to those who appreciate quality craftsmanship and performance in their marine experiences. This vessel is also suited for individuals who enjoy entertaining, as its open-plan layout allows for seamless interaction with guests, making it great for social gatherings on the water. With user-friendly operational features, the Helmsman Trawlers 43E PILOTHOUSE invites both experienced captains and those just starting their boating journey. Its blend of modern technology and traditional boating ethos ensures that it meets the diverse needs of today’s boaters, making it an excellent choice for anyone looking to explore new horizons with confidence and style.
