2005 Hatteras Enclosed BridgeSold

GALILEA sleeps up to 8 guests in 4 staterooms, plus up to 4 crew in 2 cabins.

Starting aft on the swim platform is a hot/cold shower, removable stanchions, a portable ladder for water entry/exit and a water-tight door to the crew area and engine room. Curved stairs on each side lead up to the aft deck where the outside dining table with settee and dining chairs are located. A cabinet with sink and granite top is to starboard above with a TV that drops down from the ceiling. Freshwater wash-down is also on this deck. A door to port leads down to the crew quarters and engine room, while steps to port lead up to the wheelhouse/skylounge deck.

Sliding glass doors open to a spacious full-beam salon/dining area. Directly inside to starboard is an inviting curved, granite-topped bar with ice maker, fridge and sink as well as storage.

The large comfortable sofa makes this area a favorite not only for drinks and appetizers, but also for watching TV or using a laptop. To port is a lounge area including sofa. Forward is a high-gloss oval dining table with surrounding custom dining chairs. One cabinet forward reveals the temperature-controlled wine cooler; two other lighted glass cabinets display art. Single occasional chair port aft in salon.

Two steps up from the dining area is the U-shaped galley with updated appliances and granite countertops. Beyond the galley is a large dinette and settee, used for visiting with the cook, informal eating or watching the news on the wall-mounted TV. Doors from each side open to the side decks. Across from the galley is a Sub-Zero refrigerator/freezer and stairs which curve up to the enclosed pilothouse/skylounge.

The pilothouse/skylounge forward and above with bridge and piloting functions. Two helm chairs and a well-organized up-to-date instrument console cross from one side to the other. Behind this, to port, is a raised observation settee with a small, raised table. Farther aft is a large, U-shaped, full wet bar with sink, fridge and ice maker and plenty of storage. On the other side is a lounge area with settee and cocktail table. The television is on a lift near the bar. The aft window at the bar descends electrically, making the bar directly open to the aft deck.

The aft boat deck has a table with settee and an electric barbeque grill, stairs to the main deck, davit and the tender.

Back on the main deck dining area, a starboard hallway leads forward past the day head to port, then stairs lead down to a foyer and owner/guest staterooms. Foyer cabinetry conveniently houses a washer and dryer, while another stores supplies and linens.

Aft is the full-width master stateroom with centerline king bed and a nightstand on each side. A long bureau with drawers is on each side of the room. His and her cedar-lined closets are separated by a wall-hung television. His and her bathrooms, each with their own entry, are joined together by a large luxurious shower with built-in seats. The luxuriously appointed bathrooms boast medicine cabinets; light onyx countertops and are mirrored for an extra sense of space.

Continuing forward to the guest staterooms, to port is a centerline queen-bed stateroom with a hanging locker and cabinets for storage as well as an en-suite bathroom with a tub. The starboard stateroom is configured with two single beds, over/under in an L-shape. A hanging locker and cabinets as well as en-suite bathroom complete this room. The fourth stateroom is forward with VIP centerline queen, two hanging lockers, drawers and cabinets plus en-suite bath. All baths have countertops of either onyx or marble.

On the Foredeck area, a windlass, anchor, hatch access to chain locker and a locker for the electrical cable connection to shore power are found here.

Crew area and engine room are accessed by the stairs on the aft deck or through the door on the swim platform. Descending stairs from the aft deck is the crew/engine room foyer with a full-size refrigerator/freezer and entry to the engine room forward. From the foyer aft is a captain’s cabin with centerline queen bed, hanging locker and drawers. A second cabin has over/under bunks with storage. A head with stall shower is shared.

• Solid fiberglass hull with glass/Divinycell superstructure

Dimensions

• General Length Overall: 80' 0" (24.38m)
• Beam: 21' 4" (6.50m)
• Draft: 6’ (1.83m)
• Tonnage: 125 GRT

Capacities

• Fuel Capacity: 2,158 g (8,169 l)
• Water Capacity: 388 g (1,469 l)
• Grey Water: 252 g (954 l)
• Black Water: 388 g (1,469 l)

Main Engines

• Main Engines: 2 x Caterpillar C32 Turbo charged; 1650 hp
• Engine hours: Port 2555; Stbd 2555 hours (Oct 2025)
• Gearboxes: ZF

Generators & Electricity

• Output: 120/240 V AC, single phase, 60 HZ
• Generators: (2) Onan 27.5 KW generators
• Generator hours: Port 3985; Starboard 3525 (Oct 2025)
• Shore Power: (2) Retractable shore cables: 100-amp, 50 amp with remote

Batteries

• Main Engines: 24V DC (2) 8D 12V DC; start batteries
• Generator Starting: 24V DC; start off either or both main engine start batteries
• General Service: (2) 8D Batteries

Lights

• All lights changed to LED
• Mood lighting enhanced with rope lighting and dimmer switches throughout

Air-Conditioning

• Cruise Air; 2 x chillers
• Reverse cycle heat
• Entire AC system professionally cleaned

Other Machinery

• Watermaker: Sea Recovery Aqua Whisper: SRC 1200-2AWC; 1200 gpd
• Stabilizers: Naiad multi-Sea 2000 hydraulic
• Bow Thruster: Naiad hydraulic, 38 HP
• Steering System: Hypnautic Sea Star hydraulic; pilothouse and aft deck plus Yacht Controller
• Emergency Steering: Emergency control station stored under wheelhouse console
• Sewage System: 388 g, black water fiberglass tank; discharges overboard or dockside pump-out; (7) freshwater toilets
• Fresh Water System: 388 g, (2) Headhunter pressure pumps; dockside water pressure regulator with pressure gauge
• Bilge Water System: Rule 24V submersible bilge pumps with Rule-Mate float switch and separate high bilge alarm throughout bilges
• Helm Control: wheelhouse, aft deck port drive station and remote Yacht Controller
• Misc: Central vac, 4 outlets

Communication Systems

• Satellite TV System: HD 7 KVH Direct TV system
• VHF
• Cameras: Engine room and aft deck

Navigation Systems

• Radar: Furuno FAR 2127
• ( 1) VEI 15’ Display for radar plotter, CCTV camera
• Autopilot: Simrad AP25
• Depth sounder, video sounder, sonar, wind, speed and other functions found on Garmin systems
• Compass: Richie Powerdamp magnetic compass

Ship’s Monitoring System

• Hatteras Monitor Display for Hatteras Ship’s Monitoring System (New 2019)

GPS(s)

• Garmin GPS Plotter 8000 (new 2019)
• Garmin GPS Plotter 7608 ; Wind added (All new 2019)
• Garmin GPS Plotter 5212
• Nobeltec GPS Chart System and Chart Plotter

VHF

• ICOM #IC M602
• ICOM #IC M605 (new 2019)

Misc

• FLIR night vision
• Starlink
• Nightlight
• (2) ACR spotlight controls
• Windshield wipers

Entertainment System

• TVs: 50” on lift in salon; on lift in skylounge; drop-down on aft deck; wall-mounted in all staterooms and captain’s cabin
• Audio Equipment: Various combinations of stereo/CD/VCR/DVD throughout
• Stereo: Salon has surround sound stereo, stereo speakers in aft deck

Main Galley Equipment

• Range: 4-burner induction cooktop
• Oven: Sharp carousel convection oven
• Grill: Electric grill on skylounge aft deck
• Microwave: Sharp carousel sensor microwave/convection
• Refrigeration: Sub-Zero refrigerator/freezer in galley; refrigerator/freezer in crew foyer and Scotsman fridge in skylounge bar
• Icemaker(s): (2) Scotsman in salon and skylounge bars
• Wine Cooler: U-line in dining area cabinet
• Dishwasher: KitchenAid
• Misc: Trash compactor

Laundry Equipment

• Main Laundry Washer: Whirlpool stackable washer/dryer in stateroom Foyer
• 2nd Washer: in crew area
• 2nd Dryer: in crew area

• Anchor Windlass system
• Anchors: 110 lb. plow anchor, stainless steel
• Anchor chain & rode: 300 ft. chain; 250 ft. rode
• Davit/Cranes: Quick Lift 1500 lbs. davit on flybridge aft deck
• ZAR 11ft. tender with Suzuki outboard (2015)
• Accommodation ladders: side-boarding gangway and stairs plus ladder
• Exterior Showers: hot/cold shower on aft deck/swim platform

Security Equipment

CCTV System

• Cameras: (1) engine room, (1) aft deck
• Monitors: (2) in wheelhouse
• Ship Safe: (1) master stateroom

Fire Fighting Equipment

• Fire/Heat/Smoke Detectors: overhead mounted optical smoke detectors throughout
• Fixed FM 200 system: Sea Fire # H120
• Portable CO2: 15 lb. portable fire extinguisher

A detailed list of exclusions will be provided at the time of sale, upon written request.
