2005 Caliber 40LRC SE Boat in Harpswell, ME 04079 US
Built in 2005
40LRC SE
1 Engine (Yanmar)
40 feet
Diesel
Fiberglass/Reinforced
What sets Caliber apart from the fleet of her rivals? Is it her swiftness? Her seaworthiness and durability? Her exceptional stability and comfort? As Caliber owners know, it is the artful combination of these qualities, which enables a Caliber to perform beyond the limits that constrain so many others.
This 2005 Caliber 40 LRC SE "End Game" meets all those expectations. "End Game" has standard features like Water Tight Collision Bulkhead, Water-Tight Rudder Dam, Triple Support Rudder System, Smart Fuel Panel and much more.
"End Game" is set up for long distance sailing and live-aboard comfort. She is fitted with a large fridge/freezer, propane stove and lots of storage space. With a large forward berth and aft berth, two heads, separate stall shower, hot/cold pressure water, a large comfortable salon with a capacious extending dining table, lots of ventilation makes for comfortable cruising.
In addition, her large capacity fuel and water tanks, cutter rig, makes "End Game" a true-blue water cruising sailing vessel.
"End Game" has had only one owner! The current and only owners have enjoyed the boat since 2005 cruising the waters of Maine, Virgin Islands, Leeward Islands and the Azores. "End Game" has spent most winters stored inside a heated storage building.
This Caliber 40 LRC SE is ready to go cruising for new blue water adventures!
This Caliber 40LRC SE is ready for your inspection.
- Dual alternators.
- Solar Panels
- Wind generator
- Water Maker Spectra Catalina
- ICOM 802 SSB Radio with auto antenna tuner with pactor modem
- Batteries (2024)
- Davits
- Motor lift
- Anchor wash down
- Tank Tender monitoring systems
- Caliber Smart fuel panel with dual fuel filters and vacuum gauge
- Dripless shaft seal
- Caliber Convertible Cutter rig
- Lee cloths
- Frigoboat freezer fridge keel cooler
LOA:40ft 11in /12.47M LWL: 32ft 6in feet/9.91M Beam: 12ft 8in/3.86M
Draft: 5ft 1in/ 1.55M (varies)
Displacement: 21,600 lbs/ 9,798KG Ballast: 9,500 lbs/4,309KG
All dimensions are approximate.
- Yanmar Diesel Engine JH4 engine Approx. 2500 hrs.
- Caliber Smart Fuel Control System
- Dual fuel filters with dual fuel tanks
- Fixed 3 blade prop, with line cutter.
- New Injectors (2026)
- New Injection Pump (2026)
- Cleaned heat exchanger and mixing elbow (2024)
- Starter Motor (2024)
- Line cutter on shaft
Fuel Tanks: Approx. 200 gals / 803L (2 tanks)
Water Tanks: Approx. 179 gals/625L (2 tanks)
Holding Tank: Approx. 65gals
Tank Tender monitoring System (no mechanical gauges in the tank, air pressure is used to measure tank levels)
All capacities are approximate.
Caliber's trademark* design incorporates a Multi-Bulkhead Bonding System*, an Integral Strength-Grid System* for strength and safety, integral baffled tanks act as double bottoms while adding tremendous rigidity to the hull structure, with additional strength from the integral sub-sole. Additionally, there is a Water-Tight Collision Bulkhead*.
Hulls are built for outstanding resistance to collisions, with extra layers of solid fiberglass at potential impact points. In case of damage to the bow or rudder, a Watertight Collision Bulkhead and Rudder Dam are designed to minimize flooding.
When rough water makes most sailors miserable, a Caliber owner can cruise in comfort. And with confidence. The Caliber moves more steadily in heavy seas. And due to her high ballast-to-displacement ratio, the Caliber is very stable.
A swim ladder and boarding platform built into the transom make it easy to board a dinghy or take a swim.
- Windlass Electric Lofrans Project 1000 (motor refurbished 2024)
- Outboard motor lift and mount
- Pedestal guard
- Pedestal wheel
- Mast guard
- Rail seats
- Folding teak cockpit table
- Dorade vents with guards & screen
- Low maintenance rub rail with stainless steel striker
- Low maintenance aluminum handrails on deck
- Pad eyes folding on foredeck for dingy tie down
- (6) Mooring cleats and chocks
- Mushroom vent in shower
- (7) Hatches with screens (2 hatches replaced)
- (12) opening ports with screens (rebeded)
- Cockpit ice box
- (3) Cockpit drains
- (3) Harness tie point in cockpit
- Cockpit coaming box
- Transom shower
- Pedestal mounted compass
- Two-tone non-skid
- Anchor light
- Nav lights
- Foredeck light
- LPG locker for two tanks
- Davits, Kato
- Caliber Smart anchor system
- Anchor wash down pump
- Upgraded #50 Lewmar primary winches
- Lewmar halyard winches
- Anchor roller platform with double staggered rollers
- Molded swim platform with boarding ladder and freshwater shower
- 2nd generation divided anchor locker with room for fender, fender board, dingy fuel storage & spare dock lines
- MOM 8 man overboard.
- Cockpit speakers
In terms of accommodation, no boat of comparable size comes close to the Caliber 40. Her sleeping quarters are true staterooms, expansive and private. Instead of a cramped V-berth, there's a full forward stateroom with a generous offset double berth with ample storage space and drawers below; shelf and book rack over berth; and two-door large cedar-lined hanging locker and one-door locker with shelf storage. The master fwd cabin features a private, spacious head with its own separate shower that's enclosed by a plexiglass door. Together, the forward cabin and head offer luxurious livability for extended stays.
The owners have created numerous custom storage shelfs though out the interior.
The same kind of comfort and convenience is provided in the aft stateroom with its double berth; large cedar-lined hanging locker; and private aft-head entrance.
The main salon is well illuminated and richly furnished in teak. It takes full advantage of tall headroom and a wide beam. The result is a "living room" that's perfect for entertaining guests. Two settees offer ample seating and one of them even converts into a double berth (for a total of 7 berths). Both settees have storage under and behind, and teak cabinets over. The twin-leaf dining table folds up against the bulkhead for additional space. There is an additional fold up “laptop” table when the large table is not needed.
The aft head is located conveniently to the cockpit. It's entrances from the aft cabin, and the salon make it accessible from either area without disturbing the other occupants. Both heads are completely outfitted with pressurized hot/cold water and shower.
The nav. station is port, aft of galley featuring chart table with hinged lid, with storage underneath; chart light; electronics cabinet; breaker panel; nav. seat with storage under. Beautiful teak and holly floor throughout, and multiple handrails.
- Lee clothes
- Raritan PH II Heads (2 ea.) New hoses (2023
- Corian counter tops head
- 10 Fans
- Lee cloths
- Fwd berth mattress (2016)
- 5 small hatches
- 2 large hatches with Sky Screens and shades
- 12 opening ports with screens
- Vent in shower
- Custom teak hull battens in interior
- Aplenglow interior lights
- Stereo
Any cook would appreciate this large and efficient L-shaped galley. It has ample storage for food and utensils, and more than enough counter space to prepare multi-course meals. A custom galley cabinet over the galley has increased the overall galley storage area. In addition, there is a custom galley countertop extension.
- Water Maker Spectra
- Frigiboat keel Cooled Refrig and Freezer (Controller 2013)
- Stainless-steel sinks, near centerline
- 2 water tanks, Pressure water system, pump
- Corian countertop
- Galley sink
- 2-Burner gimbal propane stove with oven
- Safety bar in front of stove
- Galley extension table
- Hot water heater with engine heat and 110v
- Hide-away trash bin
- Water filter in galley
- Propane tank two 10lb for stove (New Solenoid 2024)
- Corian counter
- Fresh and salt water foot pump
- Garmin GPS Map 7608 (2019)
- Garmin GMR 18” Fantom Radome (2019)
- Radome mast mounted on gimbal
- Garmin New backbone cables (2019)
- Airmar Depth/Temp transducers(2019)
- Airmar Speed transducers (2019)
- Garmin depth, wind, speed (2019)
- Wind GWind Aneometer (2025)
- ICOM M-802 SSB (original)
- ICOM VHF radio with remote mic (2019)
- Autopilot Garmin (2019) Edson Bronze Tiller Arm with Garmin Reactor 40 Core (2020)
- AIS Garmin Transmit and Receive (2025)
- Loud Hailer (2024)
Caliber trademarks*: Triple Support Rudder System*, Smart Fuel System
- Dripless shaft seal
- Water Maker Spectra
- Caliber Smart fuel panel with dual fuel filters and vacuum gauge
- Tank Tender monitor system (works via air pressure)
- Windlass Electric Lofrans Project 1000
- Raritan PH II Heads (2 ea) New hoses 2023
- Heads both have diverter valves for direct overboard or holding tank.
- Water heater
- Frigiboat keel Cooled Refrig and Freezer (Controller 2013)
- Holding tank deck pump-out
- Holding tank gravity drain
- Manual bilge pump
- Shower electric sump pump
- (2) Bilge electric pumps
- Single lever engine control
- Pressure water pump
- Dual water systems with inline strainers
- Engine Sea strainer with easy access
- Emergency tiller
- Engine room light
Caliber trademarks*: Smart Electrical System
- Dual Alternators
- Regulator (2016)
- Solar Panels 175watts (2021)
- Wind Generator Sea Wind (2012)
- 110V AC Electrical system
- Shore power 30 amps
- Shore power cord
- Additional DC panel
- Polarity indicator and GFI
- Batteries AGM 3 each 200amps (2024) 1 each #27 start battery
- Battery Monitor system
- Galvanic isolator
- Smart External regulator
- Battery charger 70 amp / Inventor 2500 Watt
Sail area is 739 sq. ft. (100% Fore Triangle) P=45.75' E=13.25' I=50.50' J=17.25' (all approximate)
- Selden Aluminum mast double spreaders, keel-stepped
- Standing rigging (orginal)
- Rigid boom vang with gas piston
- Mast winch two
- Mainsail fully batten stack pack design (2024)
- Selden batt car system for mainsail. (2024)
- Selden rigid boom vang with gas piston (2024)
- Three single line reef points Extra third deep reef
- Furling headsail 120% with Sunbrella sun cover. Luff flattener. (2021)
- Selden Furlex furler for headsail
- Convertible Cutter Rig Staysail Hank on (original)
- Cruising spinnaker (2017) with continues line fueler
- Storm trysail (2016)
- Boom preventor and brake
- Whisker Pole mast mount on track system.
- Standing rigging (original)
- Insulated backstay for SSB antenna
- Inboard genoa tracks
- Deck-mounted traveler with leads to cockpit
- Twin backstays
- Some running rigging replaced
- Extra jib halyard
- Spinnaker halyard
- Caliber Double Seal Integral Keel
- Water Tight Collision Bulkhead
- Water tight Rudder Dam
- Caliber Triple-Support Rudder System
- MOM 8 man overboard.
- Two anchors Rocna 40 and Fortress
- All chain rode on Rocna
- Whale manual bilge pump
- Sump electric pump
- Bilge electric pump emergency
- Emergency Tiller
- Compass
- Tri color light
- Foredeck light
- Life jackets
- Lee clothes
- Fire extinguishers
- Bimini (Original stored inside winter)
- Dodger
- Connector panel
- Hatch covers
- RibLite Inflatable 2005
- Torquedo electric outboard
- Dock lines
- Fenders
- Weems & Plath brass clock and digital barometer
- Charts paper and electronic
- Cockpit grate
- Pots dishes
- Numerous spares
NOTE: The information provided is supplied as a courtesy. Caliber Brokers, Inc. reserves the right to modify or change this information, without notice. It does not guarantee it's accuracy. All specifications and measurements are approximate. Caliber Brokers, Inc. is in no way responsible for the use of this information.
The information, photo, drawing, etc., provided is proprietary and is not to be duplicated, posted on websites or shared with any other persons, without Caliber Brokers, Inc. written permission.
Note: personal items including all tools do not convey.
It is understood that Caliber Brokers, Inc., brokers, its agents, employees, officers, and owner/seller offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his surveyor(s), to investigate such details as the buyer desires validated.
This vessel is offered subject to prior sale, price change, or withdrawal without notice. PLEASE NOTE: All electronics, electrical, mechanical, engines, spars, rigging, sails and plumbing are listed for verification purposes but not warranted in the selling price of the boat.
The information provided in the listing, emails, photos, Caliber websites, written correspondence and verbally stated were and is supplied in good faith and does not guarantee its accuracy. Details and specifications on Caliber website may not apply to all Caliber model years. Caliber Brokers, Inc., brokers, its agents, employees, officers, and owner/ seller reserve the right to modify or change this information without notice. All specifications and measurements are approximate. Caliber Brokers, Inc., brokers, its agents, employees, officers, and owner/seller are in no way responsible for the use of this information.
Both seller and purchaser agree to hold harmless and indemnify Caliber Brokers, Inc. and its agents, employees, officers, and representatives with respect to any and all claims, losses, liabilities, causes of action or damages of any nature whatsoever, including reasonable attorney’s fees, incurred by or alleged against Caliber Brokers, Inc. (a) as a result of this listing, (b) as a result of any proceedings, judicial or otherwise concerning personal liability while showing the vessel or during survey and sea trial.
Engine hours are as of the date of the original listing and are a representation of what the listing broker is told by the owner and/or actual reading of the engine hour meters. The broker cannot guarantee the true hours. It is the responsibility of the purchaser to verify engine hours, any warranties expressed or implied and/or any engine service as well as all other representations noted on the listing brochure.
It is understood and agreed by the Purchasers that once Acceptance of Vessel is approved that they have ACCEPTED THE VESSEL AS IS, WHERE IS, AND THERE IS NO WARRANTY OF MERCHANTABILITY, EITHER EXPRESSED OR IMPLIED, by Caliber Brokers, Inc., brokers, its agents, employees, officers and the owners/sellers.
Price History
| Date | Event | Price |
|---|---|---|
| 6/3/26 | Initial price | $194,950 |
Overview from around the web 2005 Caliber 40LRC SE
The 2005 Caliber 40LRC SE has gained a strong following among sailing enthusiasts, with customers highlighting a number of key features and attributes that make this vessel stand out
Many owners praise the boat's exceptional build quality and sturdy construction, noting its ability to handle rough seas with confidence. The hull design allows for a comfortable and stable sail, making it ideal for long passages or leisurely weekend trips. Customers often comment on the spacious interior layout, which maximizes living space while providing numerous amenities. The well-appointed galley, comfortable salon, and private cabins create a welcoming environment for both short journeys and extended cruising. The attention to detail in the craftsmanship is frequently noted, with many owners appreciating the high-quality materials used throughout the boat. Another point of appreciation is the performance of the Caliber 40LRC SE under sail. Sailors enjoy its responsive handling and balance, making it a joy to maneuver whether in light winds or stronger conditions. The large sail area and efficient rigging contribute to a rewarding sailing experience. In addition, many buyers express satisfaction with the steady resale value of the Caliber brand, underlining the boat’s reputation for reliability and desirability in the market. Overall, the consensus among customers is that the 2005 Caliber 40LRC SE is a well-rounded cruising yacht that delivers on performance, comfort, and durability, making it a cherished vessel for sailing adventures.
The Biggest Pros and Cons
2005 Caliber 40LRC SE Overview The Caliber 40LRC SE is a well-regarded bluewater cruising sailboat known for its robust construction, comfortable living spaces, and excellent performance. Here’s a look at the pros and cons of this exceptional vessel.
Pros
Sturdy Construction: The Caliber 40LRC SE is built with a solid fiberglass hull, ensuring durability and safety in various sea conditions. The design emphasizes offshore capability, making it suitable for long voyages.
Spacious Interior: The interior features a well-thought-out layout with ample living space. It includes a comfortable salon, a fully equipped galley, and multiple sleeping quarters, accommodating both families and cruising couples.
Excellent Performance: With a well-balanced sail plan, the 40LRC SE offers good sailing performance, capable of handling a range of wind conditions. Its fin keel and skeg-hung rudder provide stability and control while under sail.
Self-Sufficient Cruising: Many Caliber 40LRC SE models come equipped with essential cruising amenities, including a reliable power supply, water storage, and efficient systems for off-grid living, adding to its self-sufficiency for extended trips.
Community and Support: Caliber Yachts has a dedicated community of owners and a reputation for quality, meaning you'll find a wealth of resources and support available to you as an owner.
Cons
Draft Considerations: With a draft of around 5’4”, the Caliber 40LRC SE may not be suitable for all cruising grounds, especially those with shallow waters or tight anchorages.
Weight: While the sturdy construction enhances safety and performance, the added weight can sometimes translate to slower speeds under certain conditions, requiring a bit more wind to get optimal performance.
Maintenance Requirements: Like many sailboats, the Caliber 40LRC SE requires regular maintenance to keep systems running smoothly. Owners should be prepared for this commitment to ensure longevity and reliability.
Older Model Technology: Being a 2005 model, it may not come equipped with the latest technology and features found in newer yachts, which could be a consideration for those seeking state-of-the-art amenities.
Market Availability: Depending on the area and the specific model features, finding an available Caliber 40LRC SE can sometimes prove challenging, given their niche appeal and dedicated following.
Made For
The 2005 Caliber 40LRC SE is designed for the discerning sailor who values both performance and comfort on the water. This cruiser is perfect for long-distance voyages or weekend getaways, appealing to experienced sailors and those new to sailing alike. Its robust construction and seaworthy design make it ideal for bluewater cruising, while the spacious interior and thoughtful amenities ensure that you can enjoy life aboard in style and comfort. Adventurers will appreciate the 40LRC SE's ability to handle a variety of weather conditions, offering confidence and peace of mind whether you are crossing oceans or exploring coastal bays. Additionally, its generous sail area and efficient rigging system provide excellent performance, making it suitable for those who enjoy an engaging sailing experience. Families and groups will find the layout accommodating, with ample sleeping quarters, a well-appointed galley, and a comfortable salon for relaxation and socializing. The Caliber 40LRC SE is ideal for anyone seeking a reliable, versatile, and enjoyable sailing experience, ensuring that every journey is memorable.
