2026 Seawind 1170 Boat in Miami, FL 33132 US

Design features carried over to the new 1170:

• 1260 Layout with large saloon, galley down
• Saloon daybed & nav area (desk much larger and more suitable for office space)
• Front opening saloon windows with removable helm windows
• Trifold door
• Aft cockpit seating
• Twin enclosed helm
• Base boat will have folding helm seat with optional stbd side in same style
• Inboard diesels only (29hp)
• Minikeels and spade rudders

New features of the 1170:

• Full width single piece cockpit roof allowing for larger solar arrays
  • The same lithium options as 1260 + high output alternators
• Wider & flatter side decks
• Increased headroom throughout
• Longeron as standard with optional bowsprit (stayless)
• Topside chine allowing for much larger stbd aft cabin & berth.
• Aft facing portlight in aft cabins for added ventilation
• Rainwater collection
• Cockpit helm seat storage, ice box and cockpit fridge options
• Telescopic double rung transom ladder

• The overall finish of the Seawind 1170 will be consistent with a luxury world-standard yacht of this size and type. Only very high-quality equipment is used throughout.
• Finish: Full female moulded hulls & decks, exterior gelcoat finish with moulded-in non-slip surface on deck areas.
• Hull Laminate: Infused Vinyl Ester (Modified epoxy) resin laminate of the entire hull laminate. Infused Polyester resin elsewhere. Laminate specifications are certified to CE standards.
• Clear anodised aluminium mast and boom. Single Spreader, 7/8 rig.
• Standing Rigging – Forestay 3/8 (10mm) 1 x 19 Dieform wire. – Sidestays 3/8 (10mm) 1 x 19 Dieform wire – Diamonds 5/16 (8mm) 1 x 19 Dieform wire.
• Halyards – Main halyard: 12 mm Spectra rope : Heavy duty shackle. – Jib halyard: 8 mm Spectra rope. Heavy duty shackle. – Topping lift: 10 mm rope, Heavy duty shackle. – Spinnaker Halyard: 10mm rope with snap-shackle spliced to end.
• Boom outhaul.
• 2 x mainsail single line reefing fitted.
• Main halyard & reefing lines to be led back to cockpit through turning blocks and rope clutches.
• Fully battened dacron mainsail. Triple stitched reinforced construction. Leach adjustable batten end caps. Fibreglass sail battens + batten cars.
• Cruising mainsail cover with integrated lazy jack system.
• Self-tacking dacron headsail with furler. Curved headsail traveller track with end stops.
• Flush mounted hatches & portholes (12 in total) 4 x Forward deck hatches 470mm x 470mm 2 x Mid cabin deck hatches 470mm x 470mm 1 x Port mid cabin window hatch 507mm x 377mm 1 x Port bathroom window hatch 507mm x 377mm 1 x Port bathroom rear step portlight 600mm x 150mm 1 x Galley window hatch 507mm x 377mm 1 x Aft cabin window hatch 507mm x 377mm 1 x Aft cabin rear step portlight
• Fibreglass Deck Hatches: Forward anchor & storage hatches x 5
• 6 x Docking cleats: Bow, mid & stern cleats on each hull.
• 1 x Heavy duty mooring cleat on forward walkway.
• Ventilation: 2 x forward cabin hatch vents.
• Mast base turning blocks.
• 12 x Rope clutches.
• Sheet winches :
• 1 x 45 – 2 speed self tailing  at stbd helm  2 x 40 – 2 speed self tailing at port and stbd helm  1 x 40 – 2 speed self tailing at mast
• Stanchions/Rails: High quality stanchions, bow rails and stern rails with 3 life-lines. 700mm high for premium offshore safety – exceeding CE Category A requirements.
• 2 x Transom access gates with pelican hook releases.
• 2 x side access gates with pelican hook releases.
• Aft swim ladder: Telescoping stainless aft swim ladder with flat tread for comfort.
• Steering compass at port & stbd helms.
• GRP Helm seats with ice box under port side and storage plus gas locker under stb side.
• Primary Helm (port) raised upholstered helm seat with folding backrest
• Aluminium forebeam.
• Pelican striker and adjustable cable.
• 1 x Mooring rollers above foredeck.
• 2 x Anchor roller under deck. Permanent stowage position for Plough (Delta type) anchor.
• Catwalk in foam-sandwich fibreglass.
• Plastic coated open weave trampolines.
• Moulded fibreglass Targa Bar with curved mainsheet track.
• Lounge seating at aft beam.
• Full width hard top over cockpit.
• Windows over helms for sail visibility.
• Dinghy davits mounted from aft targa supports.
• Twin raised helm stations (dual) with: 2 X 32” composite steering wheels.
• Both wheels independently linked to steering system. – System offers back-up redundancy.
• Carbon fibre cross bar - rudder linkage.
• Lightweight, modern interior design.
• Synthetic timber flooring.
• Sides and cabin top lined with vinyl or moulded gelcoat.
• Polished timber dining table: Lowers to create coffee table or double bed.
• Upholstered settee.
• Nav station and chart table
• 2 x Large forward opening windows providing significant ventilation.
• Saloon windows in toughened glass.
• Saloon / cockpit doors: Moulded gelcoat tri-fold doors. Complete with folding mechanism for folding into Cockpit roof
• Removable helm windows.
• Spacious galley with Polystone counter surfaces, timber accents.
• Twin burner LPG stove & oven. Stainless steel pot holders. Flame failure device to shut off LPG immediately in event of flame going out.
• Double bowl stainless steel sink.
• Pressure hot & cold fresh water system. Single lever mixing tap.
• Refrigerator: Front opening fridge
• Spacious freezer: 150 litre top loading.
• Under bench storage with polished timber door fronts & cutlery drawers.
• Pantry / crockery cupboard
• Inboard side of galley: Over-bench cupboard with timber polished timber finished fronts..
• Trash bin
• LPG solenoid control in galley.
• Port Side Owners Cabin
• Stbd Forward and Stbd Aft Guest Cabins
• Timber doors on all private cabins.
• Port & Starboard fwd cabins : Each queen sized berth
• Aft Starboard cabin : Double berth
• Mattresses to be 150mm (6”) quilted foam upholstered.
• Cabins lined.
• 12 volt lighting.
• Storage/Cupboards.
• Simulated timber flooring.
• Polished timber lockable door.
• Manual toilet. Discharge via holding tank.
• Holding tanks built in. Discharge Pump out by shore station or directly overboard.
• 130L Waste tank
• Composite skin fittings and sea-cocks, to meet CE requirements and easily accessible
• Vanity basin with pressure hot & cold water.
• Separate shower stall with clear glass door. Wall mounted shower head & mixer tap.
• Electric shower bilge pump with direct overboard discharge.
• Large quantity cupboards / shelves to very high quality.
• Timber lockable door.
• Manual toilet. Discharge via holding tank.
• Holding discharge via shore station pump out or via direct discharge.
• Pipes, skin fittings and seacocks to be easily accessible and to meet survey requirements.
• Vanity basin with pressure hot & cold water. Shower head and basin mixer tap with electric shower bilge pump.
• Cupboard/shelves to very high quality.
• Toilet roll holder, towel rack & mounted mirror.
• High quality DC electrical switch panel with circuit breakers, LED indicator lights and voltage display.
• Marine grade tinned electrical wiring with extensive use of heat sealed connectors.
• Batteries x 3 comprising:
  • 450 Amp hour House System (2 x 225 Ah AGM / heavy duty batteries.
  • Engine cranking battery – 1 x 700 CCA AGM.
• 230amp heavy duty isolation switch.
• 12v lighting : Numerous 12v interior lamps and courtesy lights throughout.
• Red night lights in cockpit for night sailing
• 3 x USB outlets: - Nav desk - Port fwd cabin - Stbd fwd cabin
• 1x 12v outlet: - Port helm
• CE approved navigation lights.
• Deck / Steaming combination light
• Mast head anchor / riding light.
• 2x 160w flush mounted solar panels and 25amp regulator.
• Pressure hot & cold water system to galley & both bathrooms with single lever mixer
• Hot water storage system (40 liter / 8.8 gallons) .
• Fresh water tank: 500 litres (132 gallons). Remote deck filler.
• Electric fresh water pump and accumulator/surge tank.
• Fresh water tank gauge.
• Electric bilge pumps (2) with controls integral with master battery switch panel.
• Float Switches with high level alarms (2).
• Manual bilge pumps (2) in each hull.
• Manual toilets in each head.
• Port bathroom with separate shower stall.
• Starboard bathroom with dual purpose faucet & shower.
• Electric sump pump for shower drain.
• 2 x LPG bottles – 4.5kg galvanised.
• Twin Yanmar 29hp saildrive diesel engines. Fresh water cooling, rubber isolation mounts on reinforced fibreglass bed with integral oil drip pan.
• Three blade fixed propellers.
• Dual engine controls at port helm station.
• Helm console mounted engine instruments with push button start, tachometers, engine monitoring, warning systems & engine hour meters.
• Fuel tanks: Total 360 litres (95 gallons)
• Water intakes for engines protected by external strainer. (1 per engine)
• Primary Racor (or similar) water separator / fuel filter (1 per engine)
• Engine, fuel tank & fuel line installation to CE standards to meet offshore requirements.
• Electric anchor winch with chain, located in foredeck locker to give a clean deck.
• Primary anchor is 45 lb  Delta anchor type with 55m x 8mm short link galvanised chain.
• Primary anchor is stored in a specially designed anchor roller under the catwalk.
• Anchor winch has up switch at the winch plus a remote up / down control at the helm station.
• 3 x PVC Inflatable Fenders
• 4 x Mooring lines (each 15 metres x 14mm).
• Epoxy barrier coat plus 2 coats of high quality antifouling bottom paint.
• Seawind 1170 decals on each hull and stern.
