2024 Zodiac Yachtline 490

The largest of the Zodiac Yachtline Deluxe inflatables, the 490 is the big boy. We rig these with Yamaha F90's or F70's, which sound like race car engines when revved. The 490 has the deep "V" and the stern seat is moved forward a bit to support the motor and assist with planing. This boat can be expected to reach 40-45 mph on the top end, depending on conditions. The boat has a large fuel tank of 22.5 gallons, giving you a full day of play. The 490 also has many options available from the factory like a fresh water shower and picnic table, as well as synthetic teak decking and a bathing ladder.

Boat Specifications

• LOA: 16'1"
• Beam: 6'9"
• Weight: 860 lbs (Boat Only)
• Capacity: 9 persons or 2083 lbs
• Max Motor: 90 hp Long
• Rec Motor: 70 hp Long
• Tube Diameter: 20"
• Air Chambers: 5
• Fuel Tank: 23 gals
• Fabric Type: Achilles T10 CSM, 1100 dtx - "Hypalon"
• Factory Warranty: 5 Years on Structure, 1 Year on Accessories





Standard Features

V-shaped fiberglass hull with built-in planing flaps, Anchor locker with upholstered seat and backrest, Rear locker with gas strut, 1 bow D-ring, 2 stern rings, Forward & rear boarding steps with synthetic teak, Steering wheel + steering system + cable + glove box, Built-in fuel tank + gauge + fuel/water separator, Recess for extinguisher, Double pilot/co-pilot seat with removable upholstered seat and cushioned backrest, Passenger seats with removable upholstered cushion, 4 stainless steel mooring cleats, 3 lifting points, Courtesy lights, Navigation lights, Battery switch + box, Automatic bilge pump, 2 paddles, foot pump, pressure gauge, repair kit, owner's manual

Motor Specifications

• Engine Type: Yamaha F70LA 4-stroke
• Horsepower: 70 hp
• Cylinders: 4 cyl
• Shaft Length: 20"
• Steering: Remote mech
• Starter: Electric
• Weight: 253 lbs
• Full Throttle Range: 5300 - 6300 rpm
• Displacement: 996cc
• Induction System: DOHC EFI
• Warranty: 3 years

Standard Features

Electric start, remote mech steering, power trim & tilt, aluminum propeller, easy flush system

Standard Rigging

Flush mounted remote control with harness and separate keyswitch, Command Link round tach and speedo, water/fuel separator, mechanical control cables
